Sony MHC-V5 Service Manual

MHC-V5
7
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-2. SIDE L, R PANEL BLOCK
(Page 8)
2-23. FL BOARD BLOCK
(Page 27)
2-3. TOP PANEL BLOCK
(Page 9)
2-4. LOADING PANEL BLOCK
(Page 10)
2-5. CDM BLOCK-1
(Page 11)
2-6. CDM BLOCK-2
(Page 12)
2-7. DUCT
(Page 13)
2-29. VOLUME KNOB BLOCK
(Page 33)
2-8. BACK PANEL BLOCK
(Page 14)
2-9. ARAGON BOARD-1
(Page 15)
2-11. ARAGON BOARD-3
(Page 16)
2-10. ARAGON BOARD-2
(Page 16)
2-12. D-AMP BOARD-1
(Page 17)
2-13. D-AMP BOARD-2
(Page 18)
2-14. SUB CHASSIS
(Page 19)
2-15. FRONT PANEL-1
(Page 19)
2-16. FRONT PANEL-2
(Page 20)
2-17. SWITCHING REGULATOR
(SWR1)
(Page 21)
2-30. HOW TO BEND WIRE (FLAT TYPE)
(Page 34)
2-24. BLUETOOTH MODULE (BT1)
(Page 28)
2-25. USB BOARD BLOCK
(Page 29)
2-26. NFC MODULE (NFC1)
(Page 30)
2-18. FRONT PANEL (SP) BLOCK
(Page 22)
2-19. SPEAKER LED BOARD,
FRONT PANEL (SP) ASSY
(Page 23)
2-20. LOUDSPEAKER (25 cm)
(WOOFER) (SP5)
(Page 24)
2-21. LOUDSPEAKER (10 cm)
(MID: L-CH) (SP1)
(Page 25)
2-22. LOUDSPEAKER (10 cm)
(MID: R-CH) (SP3)
(Page 26)
2-27. FFC HOLDER
(Page 31)
2-28. OPTICAL PICK-UP
(CMS-S76RFS7G) (OP1)
(Page 32)

Sony MHC-V5 Specifications

General

On/off switch	Yes
Product color	Black
Recommended usage	Universal
Suitable for outdoor use	-
Speaker type	3-way
Driver diameter	250 mm
Speaker position	Front
Tweeter diameter	40 mm
Number of drivers	3
Speaker placement	Floor
Audio output channels	1.0 channels
Mid-range driver diameter	100 mm
Number of tweeter drivers	1
Recommended amplifier power (max)	240 W
Recommended amplifier power (min)	0.5 W
Impedance	5 Ω
Frequency range	- Hz
RMS rated power	1440 W
Peak Music Power Output (PMPO)	15840 W
Number of amplifier channels	2 channels
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
AC input voltage	120 V
AC input frequency	60 Hz
Type	Home audio mini system

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
