Setting the Control Panel Type
Preparation
Setting the Control Panel
Type
You can set the type of the ICP-series control panel
connected to the MVS system.
1 Display the menu.
a Open the Engineering Setup >System >Install/Unit
Config menu (7316).
2 Select the control panel.
Install/Unit Config menu
a Select “PNL1” (control panel) in the [Device]
column.
b Press [Unit Config].
The Unit Config menu (7316.8) appears.
3 Set the type of the control panel.
Unit Config menu
a In the <ICP Type> group, select the control panel
type.
In this example, select [ICP-6520].
Select the type matching the connected control
panel.
b Press [Execute].
c Check the message, then press [Yes].
The system reboots with the applied settings.
Device
Unit Config
(Example screen, which may vary from the actual screen
display.)
MVS-6520/6530/3000A screen shown.
On the MVS-3000, [DME1] is not displayed.
ICP Type Execute
