Saving Data to Removable Disk
Preparation
Saving Data to
Removable Disk
Setting Up a Removable Disk for Use
To use USB flash memory or other removable disk with
the MVS system, you must register it as a primary device
beforehand.
1
Insert the removable disk.
a Connect the USB flash memory or other removable
disk to the DEVICE connector on the side of the
menu panel or on the rear of the control panel.
ICP-6511 menu panel (side view)
ICP-6520/6530 control panel (rear view)
ICP-3000/3016 control panel (rear view)
2
Displaying the removable disk information.
Maintenance menu
a Open the Engineering Setup >System
>Maintenance menu (7317).
b In the <USB Storage Device> group, press
[Refresh].
The data capacity information of the connected
removable disk appears.
3
Set the removable disk as a primary device.
a Select the removable disk to be set in the [Mount
Point] column.
b In the <USB Storage Device> group, press [Set
Primary].
If the removable disk is not set as a primary device,
[Removable Disk] cannot be selected in the File menu.
In the <USB Storage Device> group, select [Auto
Detect] to set the primary device automatically. This is
convenient when only one removable disk is
connected.
DEVICE connector
DEVICE connector
DEVICE connector
Notes
Memo
Refresh
Total data capacity
Used capacity
Free capacity
Set Primary
Mount Point
