Video Switching (Transitions)
Basic Image Creation Operations
DME wipe
The video changes in a DME wipe pattern that uses image shrinking/magnification or other effects.
Names of Parts in the Control Panel
The positions of the principal parts and fader lever used in the following description are shown in the following figure.
ICP-6520/6530 control panel
ICP-3000/3016 control panel
Background A Background B
M/E-1 bank
PGM/PST
bank
Cross-point control block Transition control block
Fader lever Flexi Pad
2nd row
1st row
2nd row
1st row
ICP-6520 diagram shown.
M/E-1 bank
PGM/PST
bank
2nd row
1st row
2nd row
1st row
Flexi Pad
Cross-point control block Fader lever
Transition control block
ICP-3000 diagram shown.
