Applying Special Effects (Overall Signal Effects) 185
Chapter
10
DME
Operations
When Key is selected using the MVE-8000A/9000
No.
Parameter
Adjustment
1
H
Horizontal defocusing of key
signal
2
V
Vertical defocusing of key signal
3
All
Horizontal and vertical
defocusing of key signal
5 To cancel black level leaking that can occur at the edge
of the screen when the Defocus effect is enabled, press
[Clean Defocus], turning it on.
To mask the Defocus effect with a selected
pattern
Press [Mask] to display the Mask menu (4127)
( 1 p. 189), and set the pattern type and modifiers.
Blur Settings
Applying the Blur effect
1 Open the DME >Video Modify >Defocus/Blur menu
(4121).
2 Press [Blur], turning it on.
Notes
On the MKS-6570 and MVE-8000A, the Glow and
Blur effects cannot be enabled at the same time. The
effect that was turned on most recently is enabled.
3 When using the MVE-8000A/9000, in the <Blur
Mode> group, select the signal to which you want
apply the Blur effect.
Video/Key: Video signal and key signal
Video: Video signal only
Key: Key signal only
4 Set the parameters (see step 4 in “Applying the
Defocus effect” ( 1 p. 184)).
To mask the Blur effect with a selected pattern
Press [Mask] to display the Mask menu (4127)
( 1 p. 189), and set the pattern type and modifiers.
Multi Move Settings
Applying the Multi Move effect
1 Open the DME >Video Modify >Multi Move menu
(4122).
2 Press [Multi Move], turning it on.
3 Set the following parameters.
No.
Parameter
Adjustment
1
Center X
X-value of shrinking center point
2
Center Y
Y-value of shrinking center point
3
Size
Shrinking ratio
4
Aspect
Aspect ratio of shrunken images
Sepia Settings
Applying the Sepia effect
1 Open the DME >Video Modify >Color Modify menu
(4123).
2 Press [Sepia], turning it on.
3 Set the following parameters.
No.
Parameter
Adjustment
1
Mix Y
Y signal mix amount
2
Mix C
Chroma signal mix amount
3
Mix All
Y signal and chroma signal mix
amount
4 To set the color of the sepia image, press [Sepia
Color], turning it on, and adjust the following
parameters.
No.
Parameter
Adjustment
1
Luminance
Luminance
2
Saturation
Saturation
3
Hue
Hue
To mask the Sepia effect with a selected pattern
Press [Mask] to display the Mask menu (4127)
( 1 p. 189), and set the pattern type and modifiers.
Mono Settings
Applying the Mono effect
1 Open the DME >Video Modify >Color Modify menu
(4123).
2 Press [Mono], turning it on.
