Sony MZ-B10 - LCD Module; Rec Button Assy

10
MZ-B10
3-9. Rec Button Assy
3-8. LCD Module
5 LCD module
1 five screws
2 two screws
6 screw
7 REC button assy
8 two screws
9 knob (open)
4 two claws
3 claw
1 plunger solenoid
9 lever (shaft)
7 tension spring (release)
qa lever assy (release)
8 tension spring (rec
)
2 claw
3 button (rec)
cover (rec)
6 spring (lock)
4 compression spring (rec)
5 bracket assy (rec-B)
0 lever (rec-lock)
qs lever (rec)
