NAS-E35HD/SS-CE35HD
66
Pin No. Pin Name I/O Description
124 VSS - Ground terminal
125 DVDD - Power supply terminal (+3.3V)
126 USB_INT I Interrupt signal input from the USB interface
127 AC_DET O Power failure detection output terminal for the USB section
128 CVDD - Power supply terminal (+1.2V)
129 VSS - Ground terminal
130 BD_XTACN O Oscillation circuit on/off control signal output to the digital servo
131 EM_A (_14) O Address signal output to the fl ash memory
132 CVDD - Power supply terminal (+1.2V)
133 VSS - Ground terminal
134 SDTO_I O Audio serial data output to the A/D converter and D/A converter
135 BD_XRST O Reset signal output to the digital servo "L": reset
136 DVDD - Power supply terminal (+3.3V)
137, 138
EM_A (_15),
EM_A (_16)
O Address signal output to the fl ash memory
139 ACLKR0 - Not used
140 VSS - Ground terminal
141 AFSR0 - Not used
142 BCKO O Bit clock signal output to the A/D converter and D/A converter
143 EM_A (_17) O Address signal output to the fl ash memory
144 LRCKO O L/R sampling block signal output to the A/D converter and D/A converter
