Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NAS-E35HD/SS-CE35HD
82
R252 1-216-835-11 METAL CHIP 15K 5% 1/10W
R253 1-216-821-11 METAL CHIP 1K 5% 1/10W
R254 1-216-835-11 METAL CHIP 15K 5% 1/10W
R255 1-216-821-11 METAL CHIP 1K 5% 1/10W
R256 1-216-835-11 METAL CHIP 15K 5% 1/10W
R257 1-216-857-11 METAL CHIP 1M 5% 1/10W
R258 1-216-841-11 METAL CHIP 47K 5% 1/10W
R259 1-216-833-11 METAL CHIP 10K 5% 1/10W
R260 1-216-864-11 SHORT CHIP 0
R265 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R266 1-216-821-11 METAL CHIP 1K 5% 1/10W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R268 1-216-864-11 SHORT CHIP 0
R269 1-216-809-11 METAL CHIP 100 5% 1/10W
R270 1-216-809-11 METAL CHIP 100 5% 1/10W
R272 1-216-864-11 SHORT CHIP 0
R275 1-216-809-11 METAL CHIP 100 5% 1/10W
R276 1-216-841-11 METAL CHIP 47K 5% 1/10W
R277 1-216-809-11 METAL CHIP 100 5% 1/10W
R278 1-216-864-11 SHORT CHIP 0
R279 1-216-864-11 SHORT CHIP 0
R280 1-216-864-11 SHORT CHIP 0
R281 1-469-324-21 FERRITE, EMI (SMD) (2012)
R291 1-216-809-11 METAL CHIP 100 5% 1/10W
R292 1-216-809-11 METAL CHIP 100 5% 1/10W
R301 1-216-295-91 SHORT CHIP 0
R302 1-216-295-91 SHORT CHIP 0
R321 1-218-446-11 METAL CHIP 1 5% 1/10W
R322 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R323 1-216-864-11 SHORT CHIP 0
R324 1-216-845-11 METAL CHIP 100K 5% 1/10W
R325 1-216-864-11 SHORT CHIP 0
R326 1-216-864-11 SHORT CHIP 0
R401 1-216-295-91 SHORT CHIP 0
R421 1-216-821-11 METAL CHIP 1K 5% 1/10W
R422 1-216-840-11 METAL CHIP 39K 5% 1/10W
R423 1-216-864-11 SHORT CHIP 0
R425 1-216-833-11 METAL CHIP 10K 5% 1/10W
R426 1-216-837-11 METAL CHIP 22K 5% 1/10W
R432 1-216-864-11 SHORT CHIP 0
R440 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
< VIBRATOR >
X201 1-813-379-11 VIBRATOR, CRYSTAL (67.7376MHz)
************************************************************
A-1498-587-A D-AMP BOARD, COMPLETE
**********************
< CAPACITOR >
C151 1-126-960-11 ELECT 1uF 20% 50V
C152 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C153 1-126-960-11 ELECT 1uF 20% 50V
C154 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C155 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C156 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
D-AMP
C158 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C161 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C162 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C166 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C167 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C172 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C173 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C174 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C175 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C176 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C177 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C251 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C252 1-126-960-11 ELECT 1uF 20% 50V
C253 1-126-960-11 ELECT 1uF 20% 50V
C254 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C255 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C256 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C259 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C260 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C264 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C265 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C266 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C272 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C273 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C274 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C275 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C276 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C277 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C351 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C352 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C353 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C354 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C355 1-126-947-11 ELECT 47uF 20% 35V
C356 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C360 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C362 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C363 1-128-953-31 ELECT 470uF 20% 25V
C364 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C365 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C366 1-128-953-31 ELECT 470uF 20% 25V
C367 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C369 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C370 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C371 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C372 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CNP351 1-568-826-11 CONNECTOR, FFC 7P
< DIODE >
D351 6-501-774-01 DIODE MAZ8150G0LS0
< GROUND TERMINAL >
* EB351 1-537-738-21 TERMINAL, EARTH
< IC >
IC352 6-710-904-01 IC TPA3100D2PHPR
CD
