Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NAS-E35HD/SS-CE35HD
8383
< COIL >
L151 1-457-387-11 INDUCTOR 22uH
L251 1-457-387-11 INDUCTOR 22uH
< TRANSISTOR >
Q151 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q152 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q251 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q252 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q352 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q353 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q354 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q355 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R157 1-216-845-11 METAL CHIP 100K 5% 1/10W
R158 1-216-849-11 METAL CHIP 220K 5% 1/10W
R159 1-216-849-11 METAL CHIP 220K 5% 1/10W
R164 1-216-805-11 METAL CHIP 47 5% 1/10W
R165 1-216-805-11 METAL CHIP 47 5% 1/10W
R166 1-216-805-11 METAL CHIP 47 5% 1/10W
R167 1-216-805-11 METAL CHIP 47 5% 1/10W
R257 1-216-849-11 METAL CHIP 220K 5% 1/10W
R258 1-216-849-11 METAL CHIP 220K 5% 1/10W
R259 1-216-845-11 METAL CHIP 100K 5% 1/10W
R264 1-216-805-11 METAL CHIP 47 5% 1/10W
R265 1-216-805-11 METAL CHIP 47 5% 1/10W
R266 1-216-805-11 METAL CHIP 47 5% 1/10W
R267 1-216-805-11 METAL CHIP 47 5% 1/10W
R351 1-216-864-11 SHORT CHIP 0
R354 1-216-841-11 METAL CHIP 47K 5% 1/10W
R355 1-216-845-11 METAL CHIP 100K 5% 1/10W
R356 1-216-809-11 METAL CHIP 100 5% 1/10W
R357 1-216-821-11 METAL CHIP 1K 5% 1/10W
R359 1-216-864-11 SHORT CHIP 0
R362 1-216-845-11 METAL CHIP 100K 5% 1/10W
R363 1-216-845-11 METAL CHIP 100K 5% 1/10W
R364 1-216-845-11 METAL CHIP 100K 5% 1/10W
R366 1-216-845-11 METAL CHIP 100K 5% 1/10W
R368 1-216-833-11 METAL CHIP 10K 5% 1/10W
R369 1-216-833-11 METAL CHIP 10K 5% 1/10W
R370 1-216-821-11 METAL CHIP 1K 5% 1/10W
R371 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R372 1-219-393-11 METAL 0.05 10% 5W F
R373 1-216-841-11 METAL CHIP 47K 5% 1/10W
R374 1-216-864-11 SHORT CHIP 0
R375 1-216-833-11 METAL CHIP 10K 5% 1/10W
R377 1-216-845-11 METAL CHIP 100K 5% 1/10W
R378 1-216-864-11 SHORT CHIP 0
R379 1-216-833-11 METAL CHIP 10K 5% 1/10W
R380 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
A-1498-602-A D/D CON BOARD, COMPLETE
************************
7-685-645-79 SCREW +BVTP 3X6 TYPE2 IT-3
< CAPACITOR >
C919 1-112-238-21 ELECT 470uF 20% 25V
C922 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C923 1-112-231-11 ELECT 2200uF 20% 16V
C924 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C925 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C928 1-112-226-21 ELECT 470uF 20% 16V
C931 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C932 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C933 1-112-231-11 ELECT 2200uF 20% 16V
C936 1-126-767-11 ELECT 1000uF 20% 16V
C939 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C940 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C941 1-112-231-11 ELECT 2200uF 20% 16V
C942 1-112-238-21 ELECT 470uF 20% 25V
C943 1-126-933-11 ELECT 100uF 20% 16V
C947 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C948 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C949 1-112-231-11 ELECT 2200uF 20% 16V
C950 1-100-717-91 CERAMIC CHIP 1uF 16V
C952 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C953 1-126-925-91 ELECT 470uF 20% 10V
C954 1-100-717-91 CERAMIC CHIP 1uF 16V
C955 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C956 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C957 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C958 1-100-717-91 CERAMIC CHIP 1uF 16V
C959 1-126-965-91 ELECT 22uF 20% 50V
C967 1-126-960-11 ELECT 1uF 20% 50V
C968 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN903 1-815-443-11 PIN, CONNECTOR (PWB) 2P
CN908 1-819-132-11 PIN, CONNECTOR 4P
CNP904 1-568-830-11 CONNECTOR, FFC 11P
< DIODE >
D905 6-501-177-01 DIODE UDZW-TE17-13B
D906 6-501-171-01 DIODE UDZW-TE17-7.5B
D908 8-719-073-84 DIODE 31DQ06-FC5
D909 8-719-073-84 DIODE 31DQ06-FC5
D910 8-719-073-84 DIODE 31DQ06-FC5
D911 8-719-073-84 DIODE 31DQ06-FC5
D912 6-501-817-01 DIODE MA2J1110GLS0
D913 6-500-334-01 DIODE MC2836-T112-1
D914 6-501-817-01 DIODE MA2J1110GLS0
D915 6-501-046-01 DIODE 1N5402-F46
D916 6-501-046-01 DIODE 1N5402-F46
D917 6-501-046-01 DIODE 1N5402-F46
D918 6-501-171-01 DIODE UDZW-TE17-7.5B
D919 6-501-177-01 DIODE UDZW-TE17-13B
D920 6-501-817-01 DIODE MA2J1110GLS0
D921 6-501-817-01 DIODE MA2J1110GLS0
D922 6-501-817-01 DIODE MA2J1110GLS0
D924 8-719-073-84 DIODE 31DQ06-FC5
D925 6-501-817-01 DIODE MA2J1110GLS0
D926 6-501-817-01 DIODE MA2J1110GLS0
D927 6-501-817-01 DIODE MA2J1110GLS0
D928 6-501-817-01 DIODE MA2J1110GLS0
D929 6-501-817-01 DIODE MA2J1110GLS0
D930 6-501-817-01 DIODE MA2J1110GLS0
D/D COND-AMP
