Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NAS-E35HD/SS-CE35HD
8787
C239 1-126-193-11 ELECT CHIP 1uF 20% 50V
C964 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C965 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C967 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C968 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C970 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C971 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C972 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
< CONNECTOR >
CN813 1-770-160-21 PIN, CONNECTOR (PC BOARD) 2P
CNP812 1-784-863-51 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D801 6-500-848-01 DIODE MC2840-T112-1
< IC >
IC305 8-759-100-96 IC uPC4558G2
IC802 6-710-887-01 IC R5523N001B-TR-F
< JACK >
J811 1-817-615-21 CONNECTOR, SQUARE TYPE (RECE) (DMPORT)
< COIL >
L906 1-414-078-1
1 INDUCTOR 10uH
< RESISTOR >
R119 1-216-837-11 METAL CHIP 22K 5% 1/10W
R120 1-216-837-11 METAL CHIP 22K 5% 1/10W
R121 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R122 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R219 1-216-837-11 METAL CHIP 22K 5% 1/10W
R220 1-216-837-11 METAL CHIP 22K 5% 1/10W
R221 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R222 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R970 1-216-864-11 SHORT CHIP 0
R971 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R972 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R974 1-216-864-11 SHORT CHIP 0
************************************************************
HP JACK BOARD
**************
< CAPACITOR >
C122 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C123 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C124 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C222 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C223 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C224 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C313 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C314 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< DIODE >
D301 6-500-848-01 DIODE MC2840-T112-1
D302 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD/RESISTOR >
FB101 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB201 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB301 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB302 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB303 1-216-821-11 METAL CHIP 1K 5% 1/10W
< JACK >
J301 1-815-629-21 JACK (AUDIO IN)
J302 1-815-629-21 JACK (i)
< RESISTOR >
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R118 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R217 1-216-845-11 METAL CHIP 100K 5% 1/10W
R218 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
************************************************************
KEY (FRONT) BOARD
*****************
< CAPACITOR >
C602 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CNP601 1-784-727-11 CONNECTOR, FFC 5P
< IC >
IC601 6-711-556-01 IC NJL24H400B-SA
< RESISTOR >
R601 1-216-833-11 METAL CHIP 10K 5% 1/10W
R602 1-216-805-11 MET
AL CHIP 47 5% 1/10W
R603 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R605 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R606 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S601 1-762-875-21 SWITCH, KEYBOARD (Z)
S602 1-480-469-11 ENCODER, ROTARY (VOLUME)
************************************************************
KEY (L) BOARD
************
< LED >
D601 6-500-725-01 LED SLR-343VCT32 (I/1)
< TRANSISTOR >
Q601 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R607 1-216-837-11 METAL CHIP 22K 5% 1/10W
R608 1-216-833-11 METAL CHIP 10K 5% 1/10W
R609 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R610 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R611 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
KEY (FRONT)HP JACKDMP KEY (L)
