Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NAS-E35HD/SS-CE35HD
88
R612 1-216-821-11 METAL CHIP 1K 5% 1/10W
R614 1-216-833-11 METAL CHIP 10K 5% 1/10W
R615 1-216-813-11 METAL CHIP 220 5% 1/10W
< SWITCH >
S603 1-762-875-21 SWITCH, KEYBOARD (HDD u)
S604 1-762-875-21 SWITCH, KEYBOARD (USB u)
S605 1-762-875-21 SWITCH, KEYBOARD (CD u)
S606 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S607 1-762-875-21 SWITCH, KEYBOARD (x)
S608 1-762-875-21 SWITCH, KEYBOARD (l m, TUNE –)
S609 1-762-875-21 SWITCH, KEYBOARD (M L, TUNE+)
S610 1-762-875-21 SWITCH, KEYBOARD (I/1)
************************************************************
KEY (R) BOARD
*************
< RESISTOR >
R616 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R617 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R618 1-216-821-11 METAL CHIP 1K 5% 1/10W
R619 1-216-841-11 METAL CHIP 47K 5% 1/10W
R620 1-216-837-11 METAL CHIP 22K 5% 1/10W
R621 1-216-833-11 METAL CHIP 10K 5% 1/10W
R622 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R623 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R624 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R625 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S611 1-762-875-21 SWITCH, KEYBOARD (OPTIONS)
S612 1-762-875-21 SWITCH, KEYBOARD (TRANSFER)
S613 1-762-875-21 SWITCH, KEYBOARD (HDD REC)
S614 1-762-875-21 SWITCH, KEYBOARD (BACK)
S615 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S616 1-762-875-21 SWITCH, KEYBOARD (<)
S617 1-762-875-21 SWITCH, KEYBOARD (,)
S618 1-762-875-21 SWITCH, KEYBOARD (M)
S619 1-762-875-21 SWITCH, KEYBOARD (m)
S620 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S621 1-762-875-21 SWITCH, KEYBOARD (TITLE UPDATE)
(EXCEPT UK)
S621 1-762-875-21 SWITCH, KEYBOARD
(TITLE UPDATE/DAB AUTO SCAN) (UK)
************************************************************
A-1498-599-A MAIN BOARD, COMPLETE (AEP)
A-1536-379-A MAIN BOARD, COMPLETE (RU)
A-1536-382-A MAIN BOARD, COMPLETE (UK)
A-1547-154-A MAIN BOARD, COMPLETE (MX, AR)
A-1550-937-A MAIN BOARD, COMPLETE (E51)
A-1550-944-A MAIN BOARD, COMPLETE (AUS)
*********************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-126-960-11 ELECT 1uF 20% 50V
C105 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C106 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C107 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C110 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C111 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C112 1-126-160-11 ELECT 1uF 20% 50V
C113 1-126-960-11 ELECT 1uF 20% 50V
C114 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C115 1-126-160-11 ELECT 1uF 20% 50V
C116 1-126-160-11 ELECT 1uF 20% 50V
C117 1-126-960-11 ELECT 1uF 20% 50V
C118 1-126-923-91 ELECT 220uF 20% 10V
C119 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C121 1-126-960-11 ELECT 1uF 20% 50V
C122 1-126-160-11 ELECT 1uF 20% 50V (UK)
C131 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C132 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C133 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C134 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C135 1-126-960-11 ELECT 1uF 20% 50V
C136 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C137 1-126-960-11 ELECT 1uF 20% 50V
C140 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C141 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C142 1-126-160-11 ELECT 1uF 20% 50V (UK)
C143 1-126-160-11 ELECT 1uF 20% 50V
C144 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C145 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C150 1-164-360-11 CERAMIC CHIP 0.1uF 16V (AUS)
C152 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C164 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C172 1-126-960-11 ELECT 1uF 20% 50V (AUS)
C201 1-126-960-11 ELECT 1uF 20% 50V
C202 1-126-960-11 ELECT 1uF 20% 50V
C203 1-126-160-11 ELECT 1uF 20% 50V
C205 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C206 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C207 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C208 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C210 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C211 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C212 1-126-160-11 ELECT 1uF 20% 50V
C213 1-126-960-11 ELECT 1uF 20% 50V
C214 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C215 1-126-160-11 ELECT 1uF 20% 50V
C216 1-126-160-11 ELECT 1uF 20% 50V
C217 1-126-960-11 ELECT 1uF 20% 50V
C218 1-126-923-91 ELECT 220uF 20% 10V
C219 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C220 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C221 1-126-960-11 ELECT 1uF 20% 50V
C222 1-126-160-11 ELECT 1uF 20% 50V (UK)
C231 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C232 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C233 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C234 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C235 1-126-960-11 ELECT 1uF 20% 50V
C236 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C237 1-126-960-11 ELECT 1uF 20% 50V
C240 1-164-360-11 CERAMIC CHIP 0.1uF 16V
MAINKEY (L) KEY (R)
