Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NAS-E35HD/SS-CE35HD
94
0 TH02 1-805-901-11 THERMISTOR, NTC (E51, MX)
< VARISTOR >
0 VR01 1-805-481-21 VARISTOR (MX)
0 VR01 1-805-482-11 VARISTOR (EXCEPT MX)
0 VR002 1-802-094-21 VARISTOR (E51)
0 VR003 1-802-094-21 VARISTOR (E51)
************************************************************
SP TERMINAL BOARD
*****************
< CAPACITOR >
C125 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V (AUS)
C126 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (AUS)
C168 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C169 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C225 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V (AUS)
C226 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (AUS)
C268 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C269 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C316 1-164-156-11 CERAMIC CHIP 0.1uF 25V (AUS)
< CONNECTOR >
CN306 1-815-445-11 PIN, CONNECTOR (PWB) 4P
< DIODE >
D303 6-500-848-01 DIODE MC2840-T112-1 (AUS)
< JUMPER RESISTOR >
FB110 1-216-864-11 SHORT CHIP 0 (AUS)
FB210 1-216-864-11 SHORT CHIP 0 (AUS)
FB310 1-216-864-11 SHORT CHIP 0 (AUS)
< JACK >
J303 1-780-639-11 TERMINAL BOARD (SPEAKER) 2P (SPEAKER)
J304 1-778-940-11 JACK 2P (AUDIO OUT) (AUS)
************************************************************
USB JACK BOARD
***************
< CAPACITOR >
C851 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C852 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C855 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C856 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< DIODE >
D851 6-500-848-01 DIODE MC2840-T112-1
D852 6-500-848-01 DIODE MC2840-T112-1
D853 6-500-848-01 DIODE MC2840-T112-1
D854 6-500-848-01 DIODE MC2840-T112-1
< EARTH TERMINAL >
* EP851 1-537-738-21 TERMINAL, EARTH
< JUMPER RESISTOR >
FB851 1-216-864-11 SHORT CHIP 0
FB852 1-216-864-11 SHORT CHIP 0
< JACK >
J852 1-794-548-21 CONNECTOR, USB (A) (USB)
< JUMPER RESISTOR >
R873 1-216-864-11 SHORT CHIP 0
R875 1-216-864-11 SHORT CHIP 0
************************************************************
USB MICOM BOARD
****************
< CAPACITOR >
C1 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C4 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C5 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7 1-128-995-21 ELECT CHIP 100uF 20% 10V
C8 1-128-995-21 ELECT CHIP 100uF 20% 10V
C9 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C10 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C11 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C12 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C13 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C14 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C15 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C16 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C17 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C18 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C19 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C20 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C21 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C22 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C23 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C24 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C25 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C26 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C27 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C28 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C29 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C30 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C31 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C32 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C33 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C34 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C35 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C36 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C37 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C38 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C39 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C40 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C41 1-128-995-21 ELECT CHIP 100uF 20% 10V
C42 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C43 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C44 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C45 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C46 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C47 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C48 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C49 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
USB MICOMUSB JACKPOWER SP TERMINAL
