Sony NAS-E35HD - Board-Specific Component Lists

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NAS-E35HD/SS-CE35HD
9595
C50 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C51 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C52 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C53 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C54 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C55 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C56 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C57 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C58 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C59 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C60 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C61 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C62 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C63 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C64 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C65 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C66 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C67 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C68 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C69 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C70 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C71 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C72 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C73 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C74 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C75 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C76 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C77 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C78 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C79 1-128-995-21 ELECT CHIP 100uF 20% 10V
C80 1-128-995-21 ELECT CHIP 100uF 20% 10V
C81 1-128-995-21 ELECT CHIP 100uF 20% 10V
C82 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C83 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C84 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C85 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C86 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C87 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C88 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C89 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C90 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C93 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C96 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C97 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C98 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C99 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C100 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C101 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C102 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C103 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C104 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C105 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C106 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C107 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C108 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C109 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C110 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C111 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C112 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C113 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C114 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C115 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C116 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C117 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C118 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C119 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C120 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C121 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C123 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C124 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C125 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C126 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C127 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C128 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C129 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C130 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C131 1-164-845-11 CERAMIC CHIP 5PF 0.25PF 50V
C132 1-164-845-11 CERAMIC CHIP 5PF 0.25PF 50V
C133 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C136 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C138 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C139 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C140 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C141 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C142 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C144 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C145 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C146 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C147 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C149 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C150 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C151 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C158 1-128-995-21 ELECT CHIP 100uF 20% 10V
C159 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C160 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C161 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C162 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C163 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C164 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN2 1-784-857-51 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
CN3 1-784-869-51 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN6 1-774-731-21 PIN, CONNECTOR (PC BOARD) 5P
CN7 1-774-730-21 PIN, CONNECTOR (PC BOARD) 3P
CN8 1-821-796-11 CONNECTOR, SATA SMT (7P)
< DIODE >
D1 6-501-817-01 DIODE MA2J1110GLS0
D2 6-501-579-01 DIODE MC2837
< JUMPER RESISTOR/FERRITE BEAD >
FB1 1-216-295-91 SHORT CHIP 0
FB2 1-216-295-91 SHORT CHIP 0
FB3 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB4 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB5 1-216-295-91 SHORT CHIP 0
FB6 1-216-295-91 SHORT CHIP 0
FB7 1-216-295-91 SHORT CHIP 0
FB8 1-216-295-91 SHORT CHIP 0
USB MICOM
