Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NAS-E35HD/SS-CE35HD
96
FB9 1-216-295-91 SHORT CHIP 0
< IC >
IC1 (Not supplied) IC MX29LV160CTTI-70G-E35HD-03
IC2 6-711-829-01 IC D708E001BRFP266
IC3 6-711-928-01 IC W9812G6GH-75-ER10
IC4 6-710-038-01 IC S1R72005F00A300
IC5 (Not supplied)
IC TPS74801RGWR
IC6 6-709-584-01 IC MM1663DHBE
IC7 8-759-669-42 IC SN74LVC138APWR-12
IC8 6-710-963-01 IC S-1132B25-U5T1G
IC9 6-712-182-01 IC JM20339-LGCA0C
IC10 8-759-591-61 IC TC7WHU04FU (TE12R)
IC11 6-713-125-01 IC DIR9001S1PWRG4
* IC12 6-709-229-01 IC AK4554VT-8-E2
IC13 (Not supplied) IC USB2512-AEZG
IC14 6-710-624-01 IC TPS2051BDRG4
< JUMPER RESISTOR >
JR4 1-218-990-81 SHORT CHIP 0
JR7 1-218-990-81 SHORT CHIP
0
< RESISTOR >
R085 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R1 1-218-989-11 RES-CHIP 1M 5% 1/16W
R2 1-218-965-11 RES-CHIP 10K 5% 1/16W
R3 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4 1-218-990-81 SHORT CHIP 0
R5 1-218-953-11 RES-CHIP 1K 5% 1/16W
R6 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7 1-218-965-11 RES-CHIP 10K 5% 1/16W
R8 1-218-965-11 RES-CHIP 10K 5% 1/16W
R9 1-218-990-81 SHORT CHIP 0
R10 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R11 1-218-989-11 RES-CHIP 1M 5% 1/16W
R12 1-218-989-11 RES-CHIP 1M 5% 1/16W
R15 1-218-953-11 RES-CHIP 1K 5% 1/16W
R16 1-218-990-81 SHORT CHIP 0
R17 1-218-973-11 RES-CHIP 47K 5% 1/16W
R19 1-218-977-11 RES-CHIP 100K 5% 1/16W
R20 1-218-977-11 RES-CHIP 100K 5% 1/16W
R21 1-218-977-11 RES-CHIP 100K 5% 1/16W
R22 1-218-977-11 RES-CHIP 100K 5% 1/16W
R23 1-218-977-11 RES-CHIP 100K 5% 1/16W
R24 1-218-965-11 RES-CHIP 10K 5% 1/16W
R25 1-218-953-11 RES-CHIP 1K 5% 1/16W
R26 1-218-990-81 SHORT CHIP 0
R27 1-218-990-81 SHORT CHIP 0
R28 1-218-990-81 SHORT CHIP 0
R29 1-218-990-81 SHORT CHIP 0
R30 1-218-990-81 SHORT CHIP 0
R31 1-218-990-81 SHORT CHIP 0
R32 1-218-990-81 SHORT CHIP 0
R33 1-218-990-81 SHORT CHIP 0
R35 1-218-989-11 RES-CHIP 1M 5% 1/16W
R36 1-218-941-81 RES-CHIP 100 5% 1/16W
R37 1-218-990-81 SHORT CHIP 0
R38 1-218-990-81 SHORT CHIP 0
R39 1-218-990-81 SHORT CHIP 0
R40 1-218-937-11 RES-CHIP 47 5% 1/16W
R41 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R42 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R43 1-218-941-81 RES-CHIP 100 5% 1/16W
R44 1-218-990-81 SHORT CHIP 0
R46 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R47 1-218-941-81 RES-CHIP 100 5% 1/16W
R48 1-218-990-81 SHORT CHIP 0
R49 1-218-990-81 SHORT CHIP 0
R50 1-218-990-81 SHORT CHIP 0
R51 1-218-990-81 SHORT CHIP 0
R53 1-218-941-81 RES-CHIP 100 5% 1/16W
R54 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R55 1-218-990-81 SHORT CHIP 0
R56 1-218-941-81 RES-CHIP 100 5% 1/16W
R57 1-218-941-81 RES-CHIP 100 5% 1/16W
R58 1-218-941-81 RES-CHIP 100 5% 1/16W
R59 1-218-941-81 RES-CHIP 100 5% 1/16W
R60 1-218-941-81 RES-CHIP 100 5% 1/16W
R61 1-218-941-81 RES-CHIP 100 5% 1/16W
R62 1-218-990-81 SHORT CHIP 0
R63 1-218-990-81 SHORT CHIP 0
R64 1-218-941-81 RES-CHIP 100 5% 1/16W
R65 1-218-941-81 RES-CHIP 100 5% 1/16W
R66 1-218-941-81 RES-CHIP 100 5% 1/16W
R67 1-218-990-81 SHORT CHIP 0
R68 1-218-990-81 SHORT CHIP 0
R69 1-218-937-11 RES-CHIP 47 5% 1/16W
R71 1-218-990-81 SHORT CHIP 0
R72 1-218-937-11 RES-CHIP 47 5% 1/16W
R73 1-218-941-81 RES-CHIP 100 5% 1/16W
R74 1-218-990-81 SHORT CHIP 0
R75 1-218-990-81 SHORT CHIP 0
R76 1-218-990-81 SHORT CHIP 0
R77 1-218-933-11 RES-CHIP 22 5% 1/16W
R78 1-218-933-11 RES-CHIP 22 5% 1/16W
R79 1-218-937-11 RES-CHIP 47 5% 1/16W
R80 1-218-941-81 RES-CHIP 100 5% 1/16W
R82 1-218-941-81 RES-CHIP 100 5% 1/16W
R83 1-218-990-81 SHORT CHIP 0
R86 1-218-953-11 RES-CHIP 1K 5% 1/16W
R88 1-218-941-81 RES-CHIP 100 5% 1/16W
R89 1-218-990-81 SHORT CHIP 0
R90 1-218-941-81 RES-CHIP 100 5% 1/16W
R93 1-218-990-81 SHORT CHIP 0
R94 1-218-990-81 SHORT CHIP 0
R95 1-218-990-81 SHORT CHIP 0
R96 1-218-990-81 SHORT CHIP 0
R98 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R99 1-218-990-81 SHORT CHIP 0
R100 1-218-990-81 SHORT CHIP 0
R102 1-218-990-81 SHORT CHIP 0
R103 1-218-990-81 SHORT CHIP 0
R104 1-218-990-81 SHORT CHIP 0
R105 1-218-990-81 SHORT CHIP 0
R107 1-218-941-81 RES-CHIP 100 5% 1/16W
R108 1-218-941-81 RES-CHIP 100 5% 1/16W
R109 1-218-941-81 RES-CHIP 100 5% 1/16W
R110 1-218-941-81 RES-CHIP 100 5% 1/16W
R116 1-218-941-81 RES-CHIP 100 5% 1/16W
R117 1-218-990-81 SHORT CHIP 0
Note: IC1, IC5 and IC13 on the USB MICOM board cannot exchange
with single. When IC1, IC5 and IC13 on the USB MICOM board
are damaged, exchange the entire mounted board.
USB MICOM
