Sony RM-BR300 - English

Table of Contents
GB
3
GB
Table of Contents
Overview
Features ..................................................................4
Precautions .............................................................4
Location and Function of Parts ............................5
Connections and Operations
Connections ............................................................8
Connecting a Camera Equipped with a VISCA
RS-232C Connector .........................................8
Connecting a Camera Equipped with a VISCA
RS-422 Connector ............................................ 9
Connecting Multiple Cameras Equipped with
VISCA RS-232C Connector ............................9
Connecting Multiple Cameras Equipped with
VISCA RS-422 Connector .............................10
Connecting the BRU-300/300P Optical Multiplex
Unit .................................................................11
Connecting a Video Switcher ........................... 12
Turning on the Power ..........................................12
Storing the Camera Settings in Memory
– Presetting Feature .............................................13
Appendix
Troubleshooting ...................................................15
Specifications ........................................................16
Dimensions .......................................................16
Pin Assignments ...............................................17
Using the VISCA RS-422 Connector Plug ...... 18
