36
KDL-40W4100/46W4100/46W4150
KDL-40W4100/46W4100/46W4150
KDL-40W4100 ONLY
LVDS Cable Routing
40W4100 LVDS Cable has ONE WHITE UL TAPE Band
Apply 3x8mm screw to secure LVDS metal
tabs (2 places)
CAUTION:
DO NOT USE
LVDS cable screw
hole to the left.
Attach LVDS cable to
Hole ABOVE connector.
6
7
