6-4
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
AU-258
AU-258 BOARD
(Ref. No. 1000 Series)
*************
< CAPACITOR >
C002 1-126-767-11 ELECT 1000uF 20% 16V
C003 1-126-947-11 ELECT 47uF 20% 35V
C004 1-126-947-11 ELECT 47uF 20% 35V
C005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C006 1-126-947-11 ELECT 47uF 20% 35V
C007 1-126-947-11 ELECT 47uF 20% 35V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C017 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C018 1-128-528-11 ELECT 470uF 20% 25V
C019 1-128-528-11 ELECT 470uF 20% 25V
C020 1-126-967-11 ELECT 47uF 20% 50V
C022 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C023 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C024 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C033 1-126-947-11 ELECT 47uF 20% 35V
C035 1-126-947-11 ELECT 47uF 20% 35V
C036 1-100-388-21 ELECT CHIP 39uF 20% 16V
C037 1-100-388-21 ELECT CHIP 39uF 20% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C043 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C045 1-126-947-11 ELECT 47uF 20% 35V
C046 1-100-388-21 ELECT CHIP 39uF 20% 16V
C047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C048 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C050 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C051 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C053 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C054 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C055 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C056 1-126-964-11 ELECT 10uF 20% 50V
C057 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C058 1-126-964-11 ELECT 10uF 20% 50V
C060 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C061 1-126-964-11 ELECT 10uF 20% 50V
C062 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C063 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C064 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C071 1-130-473-00 MYLAR 0.0015uF 5% 50V
C072 1-130-473-00 MYLAR 0.0015uF 5% 50V
C073 1-130-473-00 MYLAR 0.0015uF 5% 50V
C074 1-130-473-00 MYLAR 0.0015uF 5% 50V
C079 1-130-473-00 MYLAR 0.0015uF 5% 50V
C080 1-130-473-00 MYLAR 0.0015uF 5% 50V
C081 1-130-467-00 MYLAR 470PF 5% 50V
C082 1-130-467-00 MYLAR 470PF 5% 50V
C083 1-130-467-00 MYLAR 470PF 5% 50V
C084 1-130-467-00 MYLAR 470PF 5% 50V
C085 1-130-467-00 MYLAR 470PF 5% 50V
C086 1-130-467-00 MYLAR 470PF 5% 50V
C087 1-130-467-00 MYLAR 470PF 5% 50V
C088 1-130-467-00 MYLAR 470PF 5% 50V
C105 1-130-467-00 MYLAR 470PF 5% 50V
C106 1-130-467-00 MYLAR 470PF 5% 50V
C107 1-130-467-00 MYLAR 470PF 5% 50V
C108 1-130-467-00 MYLAR 470PF 5% 50V
C109 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-128-552-11 ELECT 47uF 20% 63V
C120 1-128-552-11 ELECT 47uF 20% 63V
C121 1-128-552-11 ELECT 47uF 20% 63V
C122 1-128-552-11 ELECT 47uF 20% 63V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-136-165-00 FILM 0.1uF 5% 50V
C125 1-136-165-00 FILM 0.1uF 5% 50V
C126 1-136-165-00 FILM 0.1uF 5% 50V
C127 1-136-165-00 FILM 0.1uF 5% 50V
C128 1-128-552-11 ELECT 47uF 20% 63V
C129 1-128-552-11 ELECT 47uF 20% 63V
C133 1-136-165-00 FILM 0.1uF 5% 50V
