2-5
DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
2-6. SWITCHING REGULATOR
2 Two Screws
+BV3 (3-CR)
1 Connector
(PM-136 Harness,
CN201, 10P)
3 Power Board
