Sony RMT-D185A - Section 7 Electrical Adjustment; 7-1. Power Supply Output Voltage Check

7-1
DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
This section describes procedures and instructions necessary for
adjusting electrical circuits in this unit.
Instruments required:
(1) Color monitor TV
(2) Oscilloscope 1 or 2 phenomena, band width over 100 MHz,
with delay mode
(3) Frequency counter (over 8 digits)
(4) Digital multimeter
(5) Standard commander (RMT-D175A/D175P/D185A/D185P)
(6) DVD reference disc
HLX-501 (J-6090-071-A) (dual layer) (NTSC)
HLX-503 (J-6090-069-A) (single layer) (NTSC)
HLX-504 (J-6090-088-A) (single layer) (NTSC)
HLX-505 (J-6090-089-A) (dual layer) (NTSC)
7-1. POWER SUPPLY OUTPUT VOLTAGE
CHECK
Mode Except standby
Instrument Digital multimeter
EVER+5V Check
Test point CN201 pin 4
Specification 5.0 ± 0.3 Vdc
SW+3.3V Check
Test point CN201 pin 5
Specification 3.35 ± 0.2 Vdc
SW+5V Check
Test point CN201 pin 6
Specification 5.0 Vdc
SW+8V Check
Test point CN201 pin 1
Specification 8.0 ± 0.5 Vdc
EVER+11V Check
Test point CN201 pin 3
Specification 11.0 Vdc
EVER–10V Check
Test point CN201 pin q;
Specification –10.0 Vdc
Checking method:
(1) Confirm that each voltage satisfies the specification.
Caution!
Please do not touch any electrical parts at primary circuit to avoid
electrical shock.
+0.5
–1.0
+1.0
–0.5
+0.2
–0.3
SECTION 7
ELECTRICAL ADJUSTMENT
