8-8
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Not all of the parts for POWER BLOCK
(HS12S2U) are listed.
• Items marked * are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
AR : Argentina Model
AUS : Australia/NZ Model
BR : Brazilian Model
CND : Canadian Model
E : Latin America Model
EA : Saudi Arabia Model
IN : India Model
IR : Iran Model
KR : Korea Model
ME5 : PAK,MOR Model
8-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark
or dotted line with mark are critical
for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
MX : Mexican Model
MY : Malaysian Model
PX : PX Model
SP : Singapore Model
TH : Thailand Model
TW : Taiwan Model
US : USA Model
VN : Vietnam Model
IF-156 BOARD
**************
<CAPACITOR>
C401 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C403 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C404 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C405 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C406 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V
C409 1-104-665-91 ELECT 100UF 20.00% 25V
C410 1-130-479-91 MYLAR 0.0047UF 5.00% 50V
C414 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C416 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C417 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C419 1-128-131-91 ELECT 22UF 20.00% 50V
C421 1-104-660-91 CAP, ELECT 47UF
<DIODE>
D402 6-501-193-01 DIODE 1SS355WTE-17
EXCEPT (DVP-NS47P/NS57P/NS64P/NS67P)
D402 6-501-817-01 DIODE MA2J1110GLS0
(DVP-NS47P/NS57PNS64P/NS67P)
D403 6-501-193-01 DIODE 1SS355WTE-17
EXCEPT (DVP-NS47P/NS57P/NS64P/NS67P)
D403 6-501-817-01 DIODE MA2J1110GLS0
(DVP-NS47P/NS57PNS64P/NS67P)
D406 6-501-726-01 DIODE MAZ8047GMLS0
EXCEPT (DVP-NS608P)
D406 6-500-021-01 DIODE MM3Z4V7ST1 (DVP-NS608P)
<TERMINAL>
* ET402 1-537-738-21 TERMINAL, EARTH
* ET403 1-537-738-21 TERMINAL, EARTH
(DVP-NS47P/NS578P/64P/67P)
<IC>
IC404 6-808-056-01 IC 86CK74AFG-6V92(ZM
* IC406 6-600-626-01 IC GP1UW254GKC1
IC407 6-702-302-01 IC TK11133CSCL-G
IC408 6-704-114-01 IC S-80828CNUA-B8NT2G
<CHIP CONDUCTOR>
JR401 1-216-295-91 SHORT CHIP 0
JR402 1-216-295-91 SHORT CHIP 0
JR403 1-216-295-91 SHORT CHIP 0
JR404 1-216-295-91 SHORT CHIP 0
JR405 1-216-295-91 SHORT CHIP 0
JR406 1-216-295-91 SHORT CHIP 0
JR407 1-216-295-91 SHORT CHIP 0
JR408 1-216-295-91 SHORT CHIP 0
JR413 1-216-295-91 SHORT CHIP 0
<INDUCTOR>
L401 1-408-982-81 INDUCTOR 100UH
<FLUORESCENT>
ND402 1-519-930-11 VACUUM FLUORESCENT DISPLAYS
<TRANSISTOR>
Q401 8-729-106-68 TRANSISTOR 2SD1615A-GP
(DVP-NS47P/NS57P/NS508P)
Q401 8-729-056-46 TRANSISTOR 2SC5053T100Q
(DVP-NS64P/NS67P/NS608P)
Q402 8-729-106-68 TRANSISTOR 2SD1615A-GP
(DVP-NS47P/NS57P/NS508P)
Q402 8-729-056-46 TRANSISTOR 2SC5053T100Q
(DVP-NS64P/NS67P/NS608P)
IF-156
