8-9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
<RESISTOR>
R401 1-216-833-91 METAL CHIP 10K 5% 1/10W
R402 1-216-833-91 METAL CHIP 10K 5% 1/10W
R403 1-216-809-91 METAL CHIP 100 5% 1/10W
R404 1-216-809-91 METAL CHIP 100 5% 1/10W
R405 1-216-833-91 METAL CHIP 10K 5% 1/10W
R406 1-216-809-91 METAL CHIP 100 5% 1/10W
R407 1-216-809-91 METAL CHIP 100 5% 1/10W
R408 1-216-809-91 METAL CHIP 100 5% 1/10W
R409 1-216-809-91 METAL CHIP 100 5% 1/10W
R411 1-216-809-91 METAL CHIP 100 5% 1/10W
R412 1-216-833-91 METAL CHIP 10K 5% 1/10W
(DVP-NS64P/NS67P/NS608P)
R413 1-216-833-91 METAL CHIP 10K 5% 1/10W
(DVP-NS47P/NS57P/NS508P)
R414 1-216-833-91 METAL CHIP 10K 5% 1/10W
R416 1-216-833-91 METAL CHIP 10K 5% 1/10W
R417 1-216-833-91 METAL CHIP 10K 5% 1/10W
R418 1-216-833-91 METAL CHIP 10K 5% 1/10W
R419 1-216-833-91 METAL CHIP 10K 5% 1/10W
R420 1-216-810-91 METAL CHIP 120 5% 1/10W
R421 1-216-803-91 METAL CHIP 33 5% 1/10W
R422 1-216-845-91 METAL CHIP 100K 5% 1/10W
R423 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
R424 1-216-809-91 METAL CHIP 100 5% 1/10W
R426 1-216-833-91 METAL CHIP 10K 5% 1/10W
R427 1-216-838-91 METAL CHIP 27K 5% 1/10W
R433 1-216-833-91 METAL CHIP 10K 5% 1/10W
EXCEPT (DVP-NS64P/67P)
R434 1-216-833-91 METAL CHIP 10K 5% 1/10W
EXCEPT (DVP-NS64P/67P)
R436 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
(DVP-NS508P:VN/NS608P:SP/NS508P:SP,MY,TH,KR,TW)
R436 1-216-833-91 METAL CHIP 10K 5% 1/10W
(DVP-NS64P/NS67P/NS608P:E,MX,AUS,AR,BR/NS47P/
NS57P/NS508P:E,MX,AUS,AR,BR)
R436 1-216-837-91 METAL CHIP 22K 5% 1/10W
(DVP-NS608P:IN/NS508P:ME5,IN,IR)
R436 1-216-825-91 METAL CHIP 2.2K 5% 1/10W
(DVP-NS608P:EA/NS508P:EA)
R437 1-216-833-91 METAL CHIP 10K 5% 1/10W
(DVP-NS47P/NS57P/NS508P:SP,MY,TH,KR,TS,VN/NS64P/
NS67P/NS608P:SP)
R437 1-216-825-91 METAL CHIP 2.2K 5% 1/10W
(DVP-NS608P:E,AUS,AR,BR/NS508P:E,MX)
R437 1-216-837-91 METAL CHIP 22K 5% 1/10W
(DVP-NS608P:IN/NS508P:ME,IN,IR)
R447 1-216-821-91 METAL CHIP 1K 5% 1/10W
R448 1-216-833-91 METAL CHIP 10K 5% 1/10W
R449 1-216-833-91 METAL CHIP 10K 5% 1/10W
<SWITCH>
S401 1-771-874-11 SWITCH, TACT
S404 1-771-874-11 SWITCH, TACT
S406 1-771-874-11 SWITCH, TACT
<TRANSFORMER>
* T401 1-445-125-11 DC-DC CONVERTER TRANSFORMER
<VIBRATOR>
X401 1-781-472-21 VIBRATOR, CERAMIC
A-1439-798-A SERVICE ASSY, MV (NS47P/-NS57P:US)
A-1486-731-A SERVICE ASSY, MV (DVP-NS508P:MX)
A-1483-883-A SERVICE ASSY, MV (DVP-NS508P:IN)
A-1486-715-A SERVICE ASSY, MV (DVP-NS508P:IR)
A-1486-708-A SERVICE ASSY, MV (DVP-NS508P:EA)
A-1486-736-A SERVICE ASSY, MV (DVP-NS508P:E)
A-1473-770-A SERVICE ASSY, MV (DVP-NS508P:SP,TH,TW,KR,MY)
A-1483-883-A SERVICE ASSY, MV (DVP-NS508P:ME5,IN)
A-1486-722-A SERVICE ASSY, MV (DVP-NS508P:AUS)
A-1494-211-A SERVICE ASSY, MV (DVP-NS508P:AR,BR)
A-1496-805-A SERVICE ASSY, MV (DVP-NS508P:VN)
A-1441-040-A SERVICE ASSY, MV (NS64P/NS67P:CND)
A-1494-647-A
A-1487-849-A SERVICE ASSY, MV (DVP-NS608P:E)
A-1486-989-A SERVICE ASSY, MV (DVP-NS608P:SP)
A-1487-840-A SERVICE ASSY, MV (DVP-NS608P:EA,IR)
A-1487-835-A SERVICE ASSY, MV (DVP-NS608P:IN)
A-1487-830-A SERVICE ASSY, MV (DVP-NS608P:AUS)
*******************
<CAPACITOR>
* C101 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C102 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C105 1-126-786-91 ELECT 47UF 20% 16V
* C106 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C108 1-112-514-91 CERAMIC CHIP 1500PF 5% 50V
C109 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C111 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C112 1-126-786-91 ELECT 47UF 20% 16V
* C113 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C115 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C116 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C118 1-126-791-11 CAP, ELECT 10UF 10MF 16V
C119 1-100-909-11 CERAMIC CHIP 10UF 10% 6.3V
* C123 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C125 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C126 1-100-909-11 CERAMIC CHIP 10UF 10% 6.3V
C127 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C142 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
* C144 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C145 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C146 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C147 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C148 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V
C149 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C150 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
MV-57IF-156
