8-10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
C151 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C152 1-162-916-91 CERAMIC CHIP 12PF 5.00% 50V
C153 1-162-916-91 CERAMIC CHIP 12PF 5.00% 50V
C154 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C155 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C156 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C160 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C172 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C175 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C179 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C180 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C181 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C182 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C183 1-128-934-91 CERAMIC CHIP 0.33UF 20% 10V
C184 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C186 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C187 1-126-947-11 CAP, ELECT 47UF 20% 16V
C188 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C189 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C190 1-126-786-91 ELECT 47UF 20% 16V
C191 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C192 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C193 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C195 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C197 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C198 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
* C199 1-162-968-91 CERAMIC CHIP 0.0047UF 10.00% 50V
C203 1-162-970-91 CERAMIC CHIP 0.1UF 10.00% 25V
C205 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V
C206 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V
C208 1-162-970-91 CERAMIC CHIP 0.1UF 10.00% 25V
C209 1-164-677-91 CERAMIC CHIP 0.033UF 10.00% 16V
C210 1-162-970-91 CERAMIC CHIP 0.1UF 10.00% 25V
C211 1-164-677-91 CERAMIC CHIP 0.033UF 10.00% 16V
C212 1-162-970-91 CERAMIC CHIP 0.1UF 10.00% 25V
C213 1-162-970-91 CERAMIC CHIP 0.1UF 10.00% 25V
C214 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V
C216 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C217 1-126-204-21 ELECT CHIP 47UF 20.00% 16V
C218 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C219 1-162-970-91 CERAMIC CHIP 0.1UF 10.00% 25V
C220 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C221 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C222 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C223 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C224 1-162-970-91 CERAMIC CHIP 0.1UF 10.00% 25V
C225 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V
C226 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V
* C228 1-162-968-91 CERAMIC CHIP 0.0047UF 10.00% 50V
C301 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C310 1-126-947-11 CAP, ELECT 47MF
C311 1-107-820-81 CERAMIC CHIP 0.1UF 16V
C314 1-107-820-81 CERAMIC CHIP 0.1UF 16V
C409 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C410 1-126-947-11 CAP, ELECT 47MF
C411 1-126-947-11 CAP, ELECT 47MF
C413 1-126-933-91 ELECT 100UF 20.00% 16V
C414 1-164-874-81 CERAMIC CHIP 100PF 5.00% 50V
C415 1-164-882-81 CERAMIC CHIP 220PF 5.00% 16V
C417 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V
C418 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V
C419 1-164-874-81 CERAMIC CHIP 100PF 5.00% 50V
C420 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C421 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C422 1-164-937-81 CERAMIC CHIP 0.001UF 10.00% 50V
C423 1-126-964-91 ELECT 10UF 20.00% 50V
C424 1-126-964-91 ELECT 10UF 20.00% 50V
C425 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
EXCEPT (DVP-NS47P/NS57P/ND508P:E,MX)
C427 1-126-947-11 CAP, ELECT 47UF
EXCEPT (DVP-NS508P:MX,E/NS47P/NS57P)
C428 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C429 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C430 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C432 1-164-937-81 CERAMIC CHIP 0.001UF 10.00% 50V
C444 1-126-947-11 CAP, ELECT 47UF
C501 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C504 1-126-786-91 ELECT 47UF 20% 16V
C506 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C508 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C510 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C512 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C513 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C514 1-126-947-11 CAP, ELECT 47MF
<CONNECTOR>
CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P
* CN105 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
* CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
* CN501 1-506-475-11 PIN, CONNECTOR 10P
<DIODE>
D311 6-501-675-01 DIODE HZM6.8ZMWATL-E
D312 6-501-675-01 DIODE HZM6.8ZMWATL-E
D313 6-501-675-01 DIODE HZM6.8ZMWATL-E
D314 6-501-675-01 DIODE HZM6.8ZMWATL-E
D401 6-500-335-01 DIODE MC2838-T112-1
D402 6-500-334-01 DIODE MC2836-T112-1
D404 6-501-193-01 DIODE 1SS355WTE-17
<IC>
IC101 6-712-218-01 IC CXD9932R (DVP-NS47P/NS57P/508P ONLY)
IC101 6-712-219-01 IC CXD9933R (DVP-NS64P/NS67P/NS608P ONLY)
IC103 IC (EEPROM) (Refer to Notes)
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC108 6-703-224-01 IC S-80828CNNB-B8NT2G
IC110 6-707-739-01 IC MM1661JTRE
IC201 6-704-524-01 IC FAN8036L
IC303 8-759-667-17 IC L79M05TLL-SONY-TL-E
IC304 6-706-453-01 IC NJM2587V(TE2)
Notes:
MV-57 mounted PWB must be replaced if
IC103 (EEPROM IC) is damaged or not functioning.
The old MV-57 mounted PWB must be completely disposed.
MV-57
To Next Page
