Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
IC402 8-759-278-58 IC NJM4558V-TE2
IC405 6-600-430-01 IC TOTX177(F,T)
(DVP-NS508P:EXCEPT (MX,E,AR,BR)/NS608P:SP,EA)
IC406 6-703-597-01 IC BD4830G-TR
<FUSE>
PS501 1-576-892-11 FUSE 1A 32V
PS502 1-576-892-11 FUSE 1A 32V
<TRANSISTOR>
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-424-59 TRANSISTOR UN2212
Q401 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q402 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q403 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q404 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q405 8-729-010-05 TRANSISTOR MSB709-RT1
* Q407 6-551-959-01 TR IMX25T110
Q411 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
* Q412 6-551-959-01 TR IMX25T110
Q416 8-729-010-05 TRANSISTOR MSB709-RT1
Q501 6-551-458-01 TRANSISTOR KTD1624-B
Q502 8-729-027-26 TRANSISTOR DTA114YKA-T146
<RESISTOR>
R101 1-216-809-91 METAL CHIP 100 5% 1/10W
R105 1-216-864-91 SHORT CHIP 0
R107 1-216-833-91 METAL CHIP 10K 5% 1/10W
R108 1-216-857-91 METAL CHIP 1M 5% 1/10W
R110 1-216-841-91 METAL CHIP 47K 5% 1/10W
R1101 1-218-841-91 METAL CHIP 560 0.5% 1/10W
R1102 1-218-827-91 METAL CHIP 150 0.5% 1/10W
R111 1-216-809-91 METAL CHIP 100 5% 1/10W
R1110 1-216-826-91 METAL CHIP 2.7K 5% 1/10W
R1114 1-216-801-91 METAL CHIP 22 5% 1/10W
R1118 1-216-821-91 METAL CHIP 1K 5% 1/10W
R112 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R1129 1-216-845-91 METAL CHIP 100K 5% 1/10W
R113 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R1132 1-216-864-91 SHORT CHIP 0
R1134 1-216-864-91 SHORT CHIP 0
R1136 1-216-827-91 METAL CHIP 3.3K 5% 1/10W
R1138 1-216-864-91 SHORT CHIP 0
R1139 1-216-805-91 METAL CHIP 47 5% 1/10W
(DVP-NS47P/NS57P ONLY)
R1139 1-216-864-91 SHORT CHIP 0 EXCEPT (DVP-NS47P/NS57P)
R114 1-216-845-91 METAL CHIP 100K 5% 1/10W
R1140 1-216-805-91 METAL CHIP 47 5% 1/10W
(DVP-NS47P/NS57P ONLY)
R1140 1-216-864-91 SHORT CHIP 0 EXCEPT (DVP-NS47P/NS57P)
R1141 1-216-864-91 SHORT CHIP 0
R1142 1-216-805-91 METAL CHIP 47 5% 1/10W
(DVP-NS47P/NS57P ONLY)
R1142 1-216-864-91 SHORT CHIP 0 EXCEPT (DVP-NS47P/NS57P)
R1143 1-216-805-91 METAL CHIP 47 5% 1/10W
(DVP-NS47P/NS57P ONLY)
R1143 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P)
R1145 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P)
R1146 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P)
R115 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R1150 1-216-827-91 METAL CHIP 3.3K 5% 1/10W
R116 1-216-821-91 METAL CHIP 1K 5% 1/10W
R1168 1-216-864-91 SHORT CHIP 0
R117 1-216-841-91 METAL CHIP 47K 5% 1/10W
R1178 1-216-821-91 METAL CHIP 1K 5% 1/10W
R118 1-216-801-91 METAL CHIP 22 5% 1/10W
R1184 1-216-864-91 SHORT CHIP 0
R1191 1-218-990-81 SHORT CHIP 0
R1192 1-218-990-81 SHORT CHIP 0
R1193 1-218-990-81 SHORT CHIP 0
R1194 1-218-990-81 SHORT CHIP 0
R1197 1-216-864-91 SHORT CHIP 0
R1198 1-216-827-91 METAL CHIP 3.3K 5% 1/10W
R120 1-216-801-91 METAL CHIP 22 5% 1/10W
(DVP-NS608/NS508P:AUS,AR,BR,VN/NS64P/NS67P)
R1201 1-216-864-91 SHORT CHIP 0
(DVP-NS47P/NS57P/NS508P ONLY)
R1202 1-216-864-91 SHORT CHIP 0
(DVP-NS47P/NS57P/NS508P ONLY)
R1203 1-216-864-91 SHORT CHIP 0
(DVP-NS47P/NS57P/NS508P ONLY)
R121 1-216-801-91 METAL CHIP 22 5% 1/10W
EXCEPT(NS508P:AUS,AR,BR,VN/NS64P/67P/NS608P)
R1217 1-216-864-91 SHORT CHIP 0
R1218 1-216-864-91 SHORT CHIP 0
R122 1-216-833-91 METAL CHIP 10K 5% 1/10W
R124 1-216-841-91 METAL CHIP 47K 5% 1/10W
R125 1-216-833-91 METAL CHIP 10K 5% 1/10W
R130 1-216-805-91 METAL CHIP 47 5% 1/10W
(DVP-NS47P/NS57P ONLY)
R130 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P)
R131 1-216-835-91 METAL CHIP 15K 5% 1/10W
R132 1-216-805-91 METAL CHIP 47 5% 1/10W
(DVP-NS47P/NS57P ONLY)
R132 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P)
R136 1-216-864-91 SHORT CHIP 0 (DVP-NS608P ONLY)
R137 1-216-864-91 SHORT CHIP 0 (DVP-NS608P ONLY)
R138 1-216-864-91 SHORT CHIP 0 (DVP-NS608P ONLY)
R142 1-216-845-91 METAL CHIP 100K 5% 1/10W
R143 1-216-864-91 SHORT CHIP 0
R146 1-218-937-81 RES-CHIP 47 5% 1/16W
(DVP-NS47P/NS57P ONLY)
R146 1-218-990-81 SHORT CHIP 0 EXCEPT (NS47P/NS57P)
R147 1-218-937-81 RES-CHIP 47 5% 1/16W
(DVP-NS47P/NS57P ONLY)
R147 1-218-990-81 SHORT CHIP 0 EXCEPT (NS47P/NS57P)
R156 1-216-809-91 METAL CHIP 100 5% 1/10W
R191 1-216-821-91 METAL CHIP 1K 5% 1/10W
R192 1-218-827-91 METAL CHIP 150 0.5% 1/10W
R193 1-216-821-91 METAL CHIP 1K 5% 1/10W
R194 1-216-833-91 METAL CHIP 10K 5% 1/10W
R195 1-218-827-91 METAL CHIP 150 0.5% 1/10W
R197 1-218-827-91 METAL CHIP 150 0.5% 1/10W
Note :
The components identified by mark
or
dotted line with mark are critical for
safety.
Replace only with part number specified.
