DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
2-8. CIRCUIT BOARDS LOCATION
IF-156 Board
(INTERFACE)
Power Board
MV-057 Board
(SYSTEM, DRIVE, VIDEO,AUDIO, POWER)
MS-203 Board
2-7E
