5-3
DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
Pin No. Pin name Type Function
104 R/CR/PR Analog Red, CR/PR, CVBS or SY
105 AADVSS Ground Ground pin for 2ch audio DAC circuitry
106 NC Analog Not Used
107 NC Analog Not Used
108 NC Analog Not Used
109 AADVDD Power 3.3V Power pin for 2ch audio ADC circuitry
110 APLLVDD3 Power 3.3V Power pin for audio clock circuitry
111 APLLCAP Analog InOut APLL External Capacitance connection
112 ADACVSS2 Ground Ground pin for audio DAC circuitry
113 ADACVSS1 Ground Ground pin for audio DAC circuitry
114 NC Analog Output Not Used
115 NC Analog Output Not Used
116 AR Analog Output Audio DAC Right Channel Output
117 AVCM Analog Audio DAC Reference voltage
118 AL Analog Output Audio DAC Left Channel Output
119 NC Analog Output Not Used
120 NC Analog Output Not Used
121 ADACVDD1 Analog Power 3.3V Power pin for audio DAC circuitry
122 ADACVDD2 Analog Power 3.3V Power pin for audio DAC circuitry
123 AVDD18_1 Analog Power Analog 1.8V power
124 AGND18_1 Analog Ground Analog Ground
125 RFIP Analog Input AC Coupled DVD RF signal input RFIP
126 NC Analog Input Not Used
127 IOPMON Analog Input Main beam, RF AC input path
128 SPFG Analog Input Main beam, RF AC input path
