HT-CT780
61
Pin No. Pin Name I/O Description
124 SD0_0 O Digital audio signal output to the digital audio interface receiver
125 MCLK O Master clock signal output to the digital audio interface receiver
126 to 128 SD0_1 to SD0_3 O Digital audio signal output to the digital audio interface receiver
129 MUTEOUT O HDMI muting on/off control signal output terminal “H”: muting on
130 SPDIF0_OUT O S/PDIF audio signal output to the digital audio interface receiver
131 WS0_IN/GPIO11 I/O Not used
132 SCK0_IN/GPIO10 I/O Not used
133 SD0_IN/SPDIFO_IN I S/PDIF audio signal input terminal Not used
134 SCK1_IN/SCK1_OUT O Serial data transfer clock signal output terminal Not used
135 WS1_IN/WS1_OUT O Word select signal output terminal Not used
136
SD1_IN/SD1_OUT/
SPDIF1_IN/
SPDIF1_OUT
O S/PDIF audio signal output terminal Not used
137, 138 ARC0, ARC1 I Digital audio signal input terminal Not used
139 CVCC12 - Power supply terminal (+1.3V)
140 TPVDD12 - Power supply terminal (+1.3V)
141 TDVDD12 - Power supply terminal (+1.3V)
142 T1XC– O TMDS clock (negative) output terminal Not used
143 T1XC+ O TMDS clock (positive) output terminal Not used
144 T1X0– O TMDS data (negative) output terminal Not used
145 T1X0+ O TMDS data (positive) output terminal Not used
146 T1X1– O TMDS data (negative) output terminal Not used
147 T1X1+ O TMDS data (positive) output terminal Not used
148 T1X2– O TMDS data (negative) output terminal Not used
149 T1X2+ O TMDS data (positive) output terminal Not used
150 TPVDD12 - Power supply terminal (+1.3V)
151 TDVDD12 - Power supply terminal (+1.3V)
152 T0XC– O TMDS clock (negative) output to the HDMI transmitter
153 T0XC+ O TMDS clock (positive) output to the HDMI transmitter
154 T0X0– O TMDS data (negative) output to the HDMI transmitter
155 T0X0+ O TMDS data (positive) output to the HDMI transmitter
156 T0X1– O TMDS data (negative) output to the HDMI transmitter
157 T0X1+ O TMDS data (positive) output to the HDMI transmitter
158 T0X2– O TMDS data (negative) output to the HDMI transmitter
159 T0X2+ O TMDS data (positive) output to the HDMI transmitter
160 CVCC12 - Power supply terminal (+1.3V)
161 to 171 D0 to D10 I Digital video signal input terminal Not used
172 IDCK I Output data clock signal input terminal Not used
173 IOVCC33 - Power supply terminal (+3.3V)
174 to 176 D11 to D13 I Digital video signal input terminal Not used
