Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT780
70
CN1001 1-821-398-41 HDMI CONNECTOR (HDMI IN 1 [HDCP 2.2])
CN1004 1-821-398-41 HDMI CONNECTOR
(ARC [HDCP 2.2] HDMI OUT)
CN1501 1-821-398-41 HDMI CONNECTOR (HDMI IN 2)
CN1502 1-821-398-41 HDMI CONNECTOR (HDMI IN 3)
< DIODE >
D102 6-503-761-01 DIODE RB751S40, 115
D103 6-503-737-01 DIODE CES520
D104 6-503-737-01 DIODE CES520
D105 6-503-775-01 DIODE CRH02 (T5R, SONY, XM)
D106 6-502-961-01 DIODE DA2J10100L
D107 6-502-961-01 DIODE DA2J10100L
D302 6-503-737-01 DIODE CES520
D303 6-503-737-01 DIODE CES520
D501 6-502-252-01 DIODE KDZTR5.6B
D502 6-502-961-01 DIODE DA2J10100L
D503 6-503-040-01 DIODE DZ2J300M0L
D601 8-719-053-18 DIODE 1SR154-400TE-25
D602 8-719-053-18 DIODE 1SR154-400TE-25
D1801 8-719-053-18 DIODE 1SR154-400TE-25
< FUSE >
0 F501 1-523-337-11 FUSE (5 A/32 V)
0 F502 1-523-337-11 FUSE (5 A/32 V)
< FERRITE BEAD >
FB101 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB103 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB105 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB107 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB301 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB302 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB303 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB304 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB501 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB502 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB602 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB604 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB606 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB607 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB608 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1001 1-481-348-21 EMI FERRITE (SMD) (1608)
FB1002 1-400-580-21 FERRITE, EMI (SMD)
FB1003 1-481-348-21 EMI FERRITE (SMD) (1608)
FB1004 1-481-348-21 EMI FERRITE (SMD) (1608)
FB1005 1-400-580-21 FERRITE, EMI (SMD)
FB1006 1-481-348-21 EMI FERRITE (SMD) (1608)
FB1501 1-481-348-21 EMI FERRITE (SMD) (1608)
FB1502 1-400-921-21 FERRITE, EMI (SMD)
FB1503 1-400-580-21 FERRITE, EMI (SMD)
FB1504 1-469-525-91 INDUCTOR 10uH
FB1505 1-481-348-21 EMI FERRITE (SMD) (1608)
< FILTER >
FL301 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC/JACK >
IC101 6-721-894-01 IC BR24G16FJ-3GTE2
IC102 (Not supplied) IC MB9BF328SPMC-GE1 (See Note 1)
IC104 (Not supplied) IC MFI337S3959 (See Note 1)
IC105 6-717-680-01 IC BD00IC0WEFJ-E2
IC106 6-713-333-01 IC PST8429UL
IC110 6-712-825-01 IC R1154N001C-TR-FE
IC301 8-759-596-39 IC SN74LV4052APWR
IC302 8-759-278-58 IC NJM4558V-TE2
IC303 6-716-745-01 IC PCM9211PTR
IC304 6-718-999-01 IC MM1839A50NRE
IC306 6-719-198-01 IC MM3411A33URE
IC307 (Not supplied) IC W25Q16DVSSIG (See Note 1)
IC308 (Not supplied) IC ADSST-AVR-3045 (See Note 1)
IC309 6-707-870-01 IC TC74VHC157FT (EK)
IC310 6-710-388-01 IC 74LVC1G79GW-125
IC311 6-704-099-01 IC TC7WZ08FK
IC312 8-759-655-22 IC TC7WH34FK
IC313 (Not supplied) IC RT8295ALZSP (See Note 1)
IC501 6-718-105-01 IC TAS5534DGGR
IC502 6-718-377-01 IC BD00C0AWFP-E2
IC503 6-721-021-01 IC TAS5624ADDVR (See Note 2)
IC601 (Not supplied) IC RT8295ALZSP (See Note 1)
IC602 (Not supplied) IC RT8295ALZSP (See Note 1)
IC603 (Not supplied) IC TPS542941PWPR (See Note 1)
IC604 6-719-139-01 IC MM3411A50NRE
IC605 (Not supplied) IC BD00IC0WHFV-GTR (See Note 1)
IC1001 6-719-062-01 IC W25X20CLSNIG
IC1002 (Not supplied) IC SII9679CNUC (See Note 1)
IC1003 6-719-062-01 IC W25X20CLSNIG
IC1004 (Not supplied) IC SII9678CNUC
IC1005 6-718-999-01 IC MM1839A50NRE
IC1006 6-709-888-01 IC TC7WHU04FK
IC1501 (Not supplied) IC SII9573CTUC
IC1801 1-843-541-11 OPTICAL RECEIVER JACK (TV DIGITAL IN)
IC1802 6-720-030-01 IC TPS2065CDBVR
< JACK >
* J1801 1-842-576-11 MINI JACK (RA) (ANALOG IN)
< JUMPER RESISTOR >
JC501 1-216-864-11 SHORT CHIP 0
JC502 1-216-864-11 SHORT CHIP 0
JC503 1-216-864-11 SHORT CHIP 0
JC504 1-216-864-11 SHORT CHIP 0
JC505 1-216-864-11 SHORT CHIP 0
JC506 1-216-864-11 SHORT CHIP 0
< COIL >
L301 1-481-524-11 INDUCTOR 10uH
L302 1-481-524-11 INDUCTOR 10uH
L303 1-481-524-11 INDUCTOR 10uH
L304 1-400-922-11 INDUCTOR 220uH
L305 1-412-975-31 INDUCTOR 0.47uH
L306 1-412-977-41 INDUCTOR 0.68uH
L307 1-412-977-41 INDUCTOR 0.68uH
L308 1-460-601-11 COIL, CHOKE 10uH
L501 1-469-555-21 INDUCTOR 10uH
L503 1-482-182-11 CHOKE COIL (SMD 10uH)
Note 1: IC102, IC104, IC307, IC308, IC313, IC601 to IC603, IC605,
IC1002, IC1004 and IC1501 on the MAIN board cannot re-
place with single. When these parts are damaged, replace the
complete mounted board.
Note 2: When the IC503 on the MAIN board is replaced, refer to
“NOTE OF REPLACING THE IC503 ON THE MAIN
BOARD AND THE COMPLETE MAIN BOARD” on page 5.
MAIN
