Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
46
HCD-EP50
U4 1-693-564-11 TUNER (AEP, CH, UK)
U6 8-759-473-59 IC LC75392
U7 8-759-231-58 IC TA7812S
U8 8-759-701-75 IC NJM7805FA
U9 8-759-576-76 IC TDA2822D013TR
U10 8-759-701-59 IC NJM78M09FA
U11 6-700-957-01 IC LA4282
U12 8-759-079-42 IC uPC1330HA-NA
U13 6-700-579-01 IC AN7312
U14 8-759-933-50 IC BA335
U15 8-759-009-22 IC MC14094BF
< VIBRATOR >
X2 1-577-126-11 VIBRATOR, CRYSTAL (7.2MHz)
< DIODE >
Z1 8-719-947-13 DIODE MTZJ-T-72-4.7B
Z2 8-719-110-17 DIODE RD10ESB2
Z4 8-719-110-36 DIODE MTZJ-T-72-13B
ZD901 8-719-983-63 DIODE MTZJ-T-72-3.3B
(EXCEPT AEP, CH, UK)
**************************************************************
A-4727-041-A POWER BOARD, COMPLETE
(AEP, AR, CH, HK, SP, UK)
A-4727-282-A POWER BOARD, COMPLETE (CND, MX, US)
***********************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C601 1-119-940-51 ELECT 4700uF 20% 50V
C602 1-126-963-11 ELECT 4.7uF 20% 50V
C604 1-128-551-11 ELECT 22uF 20% 25V
C605 1-164-159-21 CERAMIC 0.1uF 50V
C606 1-164-159-21 CERAMIC 0.1uF 50V
C608 1-164-159-21 CERAMIC 0.1uF 50V
C609 1-164-159-21 CERAMIC 0.1uF 50V
0C610 1-113-889-11 CERAMIC 0.001uF 10% 250V
C611 1-164-159-21 CERAMIC 0.1uF 50V
C612 1-164-159-21 CERAMIC 0.1uF 50V
C615 1-126-935-11 ELECT 470uF 20% 16V
C618 1-164-159-21 CERAMIC 0.1uF 50V
C626 1-126-943-11 ELECT 2200uF 20% 25V
C627 1-164-159-21 CERAMIC 0.1uF 50V
C641 1-164-159-21 CERAMIC 0.1uF 50V
C643 1-164-159-21 CERAMIC 0.1uF 50V
C644 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN601 1-506-710-11 PLUG, CONNECTOR (2.5mm) 8P
< DIODE >
D601 8-719-077-63 DIODE 1N5402
D602 8-719-077-63 DIODE 1N5402
D603 8-719-077-63 DIODE 1N5402
D604 8-719-077-63 DIODE 1N5402
D605 8-719-200-02 DIODE 10E2
D606 8-719-200-02 DIODE 10E2
D607 8-719-200-02 DIODE 10E2
D608 8-719-200-02 DIODE 10E2
D612 8-719-991-33 DIODE 1SS133T-77
D613 8-719-991-33 DIODE 1SS133T-77
D615 8-719-200-02 DIODE 10E2
D616 8-719-200-02 DIODE 10E2
D617 8-719-200-02 DIODE 10E2
D618 8-719-200-02 DIODE 10E2
D621 8-719-200-02 DIODE 10E2
< FUSE >
0F601 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5) (4A/125V)
(CND, MX, US)
0F601 1-533-471-11 FUSE, GLASS TUBE (DIA.5) (T4AL/250V)
(AEP, AR, CH, HK, SP, UK)
0F602 1-533-296-11 FUSE, GLASS CYLINDRICAL (DIA.5) (2A/125V)
(CND, MX, US)
0F602 1-533-468-11 FUSE, GLASS TUBE (DIA.5) (T2AL/250V)
(AEP, AR, CH, HK, SP, UK)
< COIL >
0L601 1-424-944-11 INDUCTOR 400uH
< TRANSISTOR >
Q605 8-729-173-38 TRANSISTOR 2SA733-K
Q606 8-729-281-53 TRANSISTOR 2SC1815-GR
< RESISTOR >
R602 1-249-407-11 CARBON 150 5% 1/4W
R603 1-249-426-11 CARBON 5.6K 5% 1/4W
R618 1-249-437-11 CARBON 47K 5% 1/4W
R619 1-249-417-11 CARBON 1K 5% 1/4W
R621 1-249-437-11 CARBON 47K 5% 1/4W
R622 1-249-403-11 CARBON 68 5% 1/4W
R623 1-249-437-11 CARBON 47K 5% 1/4W
0R625 1-219-237-11 SOLID 3.3M 20% 1/2W
(CND, MX, US)
< RELAY >
0RE601 1-755-446-11 RELAY (AEP, AR, CH, HK, SP, UK)
0RE601 1-755-448-11 RELAY (CND, MX, US)
< TRANSFORMER >
0T602 1-437-462-11 TRANSFORMER, POWER
(AEP, AR, CH, HK, SP, UK)
0T602 1-437-475-11 TRANSFORMER, POWER (CND, MX, US)
< DIODE >
Z601 8-719-109-93 DIODE RD6.2ESB2
**************************************************************
MISCELLANEOUS
**************
06 1-555-750-00 CORD, POWER (AEP, HK, SP, UK)
06 1-782-464-21 CORD, POWER (CH)
06 1-783-525-31 CORD, POWER (TRACKING) (MX)
06 1-783-820-11 CORD, POWER (CND, US)
06 1-783-941-51 CORD, POWER (AR)
MAIN POWER
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Ver 1.1
