Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
47
HCD-EP50
64 1-796-228-11 DECK, MECH (TCM) (CRL3439)
157 1-471-144-11 MAGNET
166 1-796-189-11 MECH, CD (CS-21SC-1280)
SW300 1-692-960-21 SWITCH, PUSH (1 KEY) (OPEN/CLOSE)
0T601 1-437-513-11 TRANSFORMER, POWER
(AEP, AR, CH, HK, SP, UK)
0T601 1-437-514-11 TRANSFORMER, POWER (CND, MX, US)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
#2 7-685-647-14 SCREW +BVTP 3X10 TYPE2 SLIT
#3 7-682-246-04 SCREW +K 3X5
#4 7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S
#5 7-685-648-14 SCREW +BVTP 3X12 TYPE2 SLIT
#6 7-685-504-19 SCREW +BTP 2X6 TYPE2 N-S
#7 7-623-916-21 FIBER WASHER 3.3,SMALL
#8 7-685-233-19 SCREW +KTP 2.6X6 TYPE2NON-SLIT
#9 7-624-106-04 STOP RING 3.0, TYPE -E
#11 7-685-135-19 SCREW (+ PTPWH) (2.6X10)
#12 7-685-646-14 SCREW +BVTP 3X8 TYPE2 SLIT
************************************************************
ACCESSORIES
************
0 1-569-008-21 ADAPTOR, CONVERSION (SP)
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK, HK)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Ver 1.1
