Sony STR-DA3200ES - Page 113

113
STR-DA3200ES/DG1000
Pin No. Pin Name I/O
Description
58
GND - Ground terminal
59
VDDEXT - Power supply terminal (+3.3V)
60
VDDINT - Power supply terminal (+1.2V)
61
GND - Ground terminal
62
PF_CE I/O Chip enable signal input/output terminal Not used
63 SPI_MAS O
Master/slave selection signal output terminal "L": DSP is master
64 DPSOA O
PCM audio signal (front L/R) output terminal
65 DPSOB O
PCM audio signal (surround L/R) output terminal
66
VDDINT - Power supply terminal (+1.2V)
67
GND - Ground terminal
68
VDDINT - Power supply terminal (+1.2V)
69
GND - Ground terminal
70 DPSOC O
PCM audio signal (center, sub woofer) output terminal
71 DPSOD O
PCM audio signal (surround back L/R) output terminal
72
VDDINT - Power supply terminal (+1.2V)
73
VDDEXT - Power supply terminal (+3.3V)
74
GND - Ground terminal
75
VDDINT - Power supply terminal (+1.2V)
76
GND - Ground terminal
77
DPSOE O PCM audio signal output terminal Not used
78 DPSIA I
PCM audio signal (digital input) input terminal
79 DPSIB I
PCM audio signal (front L/R) input terminal
80 DPSIC I
PCM audio signal (surround L/R) input terminal
81 DPSID I
PCM audio signal (center, sub woofer) input terminal
82 DPSIE I
PCM audio signal (surround back L/R) input terminal
83
VDDINT - Power supply terminal (+1.2V)
84, 85
GND - Ground terminal
86 DPDVLRCK O
L/R sampling clock signal (44.1 kHz) output terminal for PCM audio output
87 DPDVBCK O
Bit clock signal (2.8224 MHz) output terminal for PCM audio output
88 DPLRCK I
L/R sampling clock signal (44.1 kHz) input terminal for PCM audio input
89 DPBCK I
Bit clock signal (2.8224 MHz) input terminal for PCM audio input
90
VDDINT - Power supply terminal (+1.2V)
91, 92
GND - Ground terminal
93
VDDEXT - Power supply terminal (+3.3V)
94 DPFSCK I
Master clock signal input terminal
95
GND - Ground terminal
96
VDDINT - Power supply terminal (+1.2V)
97 XNONAUDIO I
Digital input signal switch control signal input terminal
98
XSF_CE
O
Chip enable signal output to the flash memory
99
VDDINT - Power supply terminal (+1.2V)
100
GND - Ground terminal
101
VDDINT - Power supply terminal (+1.2V)
102
GND - Ground terminal
103
VDDINT - Power supply terminal (+1.2V)
104
GND - Ground terminal
105
VDDINT - Power supply terminal (+1.2V)
106
GND - Ground terminal
