Sony STR-DA3200ES Service Manual

8282
STR-DA3200ES/DG1000
STR-DA3200ES/DG1000
6-51. PRINTED WIRING BOARD – VIDEO 3 Board –
• See page 40 for Circuit Boards Location.
: Uses unleaded solder.
8
14
5
R762
R763
R764
R765
R766 R767
R768
R769
R770
R775
R776
R774
R785R786
C759
C760
C761
C762
C763
C764
C765
C766
C767
C769
IC706
C768
7
1
16
1
5
13
1
8
J702
J703
CN720
CN721
CN722
CN724
C758
ET702
ET703
IC707
CN723
CN725
C757
JW800
JW801
JW802
JW803
VIDEO 3 BOARD
(CHASSIS)
(CHASSIS)
E
DIGITAL
BOARD
CN2015
C
ANALOG
BOARD
CN606
B
ANALOG
BOARD
CN606
A
DISPLAY
BOARD
CN706
D
S-VIDEO
BOARD
CNP6902
1-869-842-
11
(14, 15)
S VIDEO
VIDEO
VIDEO 3 IN/
PORTABLE AV IN
DIGITAL
(OPT)
AUDIO L AUDIO R
PHONES
13
A
B
C
1 2 3 4 5
(Page 84)
(Page 62)
(Page 80)
(Page 62)
(Page 47)

Sony STR-DA3200ES Specifications

Audio

impedance	8 Ohm
channel power rating	120 Watts X 7 Amp
zones	2 Zone/2 Room

Inputs and Outputs

s-video outputs	1 (Rear)
composite video outputs	3 (Rear)
optical audio outputs	1 (Rear)

Power

power requirements	AC 120V, 60 Hz
power consumption (in operation)	TBD
power consumption (in standby)	TBD

Weight and Dimensions

weight	34 lbs 3oz (15.5kg)
measurements	17" x 7" x 17" (430mm x 175mm x 430mm)
color	Black
