Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
151
STR-DA3200ES/DG1000
C3694 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3697 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3698 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3699 1-165-672-21 ELECT CHIP 47uF 20% 10V
C3700 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3701 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3702 1-126-246-11 ELECT CHIP 220uF 20% 4V
C3703 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3704 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3705 1-128-396-11 ELECT CHIP 470uF 20% 10V
C3706 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3708 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3709 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3710 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3711 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C3712 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C3713 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3714 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3715 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3716 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3717 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3718 1-124-779-00 ELECT CHIP 10uF 20% 16V
C3719 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3720 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3721 1-124-779-00 ELECT CHIP 10uF 20% 16V
C3722 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3723 1-124-779-00 ELECT CHIP 10uF 20% 16V
C3724 1-126-246-11 ELECT CHIP 220uF 20% 4V
C3725 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3726 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3727 1-124-779-00 ELECT CHIP 10uF 20% 16V
C3728 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3729 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3730 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3731 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3732 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3733 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3734 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3735 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C3736 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3737 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3738 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3739 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3740 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3741 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3742 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3743 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3744 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3745 1-165-672-21 ELECT CHIP 47uF 20% 10V
C3746 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3747 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3748 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3749 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3770 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3771 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3772 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3773 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3774 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3776 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3780 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C3781 1-114-285-11 ELECT CHIP 220uF 20% 2V
C3782 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C3783 1-114-285-11 ELECT CHIP 220uF 20% 2V
C3859 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3890 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3902 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
* CN3503 1-793-155-11 CONNECTOR, FFC/FPC 5P
* CN3505 1-817-097-21 PIN, CONNECTOR (1.5mm) (SMD) 13P
CN3506 1-815-875-21 PIN, CONNECTOR (PC BOARD) (12P)
CN3507 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
* CN3508 1-778-616-21 PIN, CONNECTOR (PC BOARD) 13P
* CN3509 1-691-551-11 PIN, CONNECTOR (SMD) 8P
CN3520 1-820-492-11 CONNECTOR, BOARD TO BOARD 10P
(DA3200ES: US, CND/DG1000)
CN5001 1-820-735-11 HDMI CONNECTOR (HDMI ASSIGNABLE IN 1)
CN5002 1-820-735-11 HDMI CONNECTOR (HDMI ASSIGNABLE IN 2)
CN5003 1-820-735-11 HDMI CONNECTOR (HDMI OUT)
< DIODE >
D3505 6-500-219-01 DIODE 1SS404 (TPH3)
D3506 6-500-219-01 DIODE 1SS404 (TPH3)
D3507 6-500-219-01 DIODE 1SS404 (TPH3)
D3508 8-719-988-61 DIODE 1SS355TE-17
D3509 8-719-988-61 DIODE 1SS355TE-17
D3511 6-500-701-01 DIODE PGB1010603NR
D3512 6-500-701-01 DIODE PGB1010603NR
< JUMPER RESISTOR/FERRITE BEAD >
FB3501 1-216-864-11 SHORT CHIP 0
FB3502 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3503 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3504 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3505 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3506 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3507 1-216-864-11 SHORT CHIP 0
< IC >
IC3501 8-759-389-26 IC 74LCX08MTCX
IC3502 6-704-001-01 IC BR24L02F-WE2
IC3504 8-759-596-39 IC SN74LV4052APWR
IC3505 (Not supplied) IC SII9033CTU
IC3508 (Not supplied) IC SII9030CTU-7
IC3509 6-806-953-01 IC uPD70F3210HYGC-8BT-AA32X103
IC3510 8-759-832-05 IC BA18BC0FP-E2
IC3511 6-705-338-01 IC TK11250CMCL-G
IC3512 6-705-337-01 IC TK11150CSCL-G
IC3513 6-705-468-01 IC BA33BC0FP-E2
IC3514 6-705-468-01 IC BA33BC0FP-E2
IC3515 6-707-149-01 IC BA25BC0WFP-E2
IC3516 6-706-521-01 IC CXD9837R
HDMI
Note: When IC3505 and IC3508 on the HDMI board are damaged, exchange
the new HDMI board for the HDMI board which IC damaged.
