STR-DA3200ES/DG1000
RB3521 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3522 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3523 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3524 1-233-575-11 RES, CHIP NETWORK 22 (3216)
RB3525 1-233-575-11 RES, CHIP NETWORK 22 (3216)
RB3526 1-233-575-11 RES, CHIP NETWORK 22 (3216)
< VIBRATOR >
X3501 1-813-570-21 VIBRATOR, CRYSTAL (28.322MHz)
X3502 1-813-562-21 VIBRATOR, CERAMIC 10.000MHZ (10MHz)
X3503 1-813-715-11 OSCILLATOR, CRYSTAL (28.63636MHZ
(28.63636MHz)
************************************************************
KEY 1 BOARD
***********
< CONNECTOR >
* CN715 1-568-941-11 PIN, CONNECTOR 3P
< RESISTOR >
R760 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R761 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
< SWITCH >
S720 1-771-349-21 SWITCH, KEYBOARD (MULTI CH IN)
S721 1-771-349-21 SWITCH, KEYBOARD (HDMI)
************************************************************
KEY 2 BOARD
***********
< CONNECTOR >
* CN727 1-568-941-11 PIN, CONNECTOR 3P
< RESISTOR >
R784 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
< SWITCH >
S725 1-771-349-21 SWITCH, KEYBOARD
(SPEAKERS (OFF/A/B/A+B))
************************************************************
M-VOL BOARD
************
< CONNECTOR >
* CN716 1-564-725-11 PIN, CONNECTOR (SMALL TYPE) 9P
CN717 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< SWITCH >
S722 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
************************************************************
A-1183-224-A MAIN BOARD, COMPLETE
(DA3200ES: AEP, UK)
A-1183-450-A MAIN BOARD, COMPLETE
(DA3200ES: US, CND, TW/DG1000)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-128-809-11 CERAMIC 100PF 5% 50V
C1002 1-128-809-11 CERAMIC 100PF 5% 50V
C1003 1-128-825-11 CERAMIC 2200PF 5% 50V
C1004 1-128-809-11 CERAMIC 100PF 5% 50V
C1005 1-128-809-11 CERAMIC 100PF 5% 50V
C1006 1-128-809-11 CERAMIC 100PF 5% 50V
C1007 1-128-809-11 CERAMIC 100PF 5% 50V
C1008 1-128-809-11 CERAMIC 100PF 5% 50V
C1009 1-128-809-11 CERAMIC 100PF 5% 50V
C1010 1-128-825-11 CERAMIC 2200PF 5% 50V
C1011 1-128-825-11 CERAMIC 2200PF 5% 50V
C1012 1-128-825-11 CERAMIC 2200PF 5% 50V
C1013 1-127-876-11 CERAMIC 0.01uF 10% 50V
C1014 1-128-809-11 CERAMIC 100PF 5% 50V
C1015 1-112-114-11 ELECT 22uF 20% 50V
C1016 1-112-114-11 ELECT 22uF 20% 50V
C1017 1-112-114-11 ELECT 22uF 20% 50V
C1018 1-112-114-11 ELECT 22uF 20% 50V
C1019 1-112-114-11 ELECT 22uF 20% 50V
C1020 1-112-114-11 ELECT 22uF 20% 50V
C1021 1-112-114-11 ELECT 22uF 20% 50V
C1022 1-112-114-11 ELECT 22uF 20% 50V
C1101 1-128-821-11 CERAMIC 1000PF 5% 50V
C1102 1-128-821-11 CERAMIC 1000PF 5% 50V
C1103 1-128-809-11 CERAMIC 100PF 5% 50V
C1104 1-128-809-11 CERAMIC 100PF 5% 50V
C1106 1-128-809-11 CERAMIC 100PF 5% 50V
C1107 1-128-809-11 CERAMIC 100PF 5% 50V
C1108 1-128-809-11 CERAMIC 100PF 5% 50V
C1109 1-128-809-11 CERAMIC 100PF 5% 50V
C1111 1-128-809-11 CERAMIC 100PF 5% 50V
C1112 1-128-809-11 CERAMIC 100PF 5% 50V
C1113 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1114 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1115 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1116 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1117 1-112-114-11 ELECT 22uF 20% 50V
C1118 1-112-114-11 ELECT 22uF 20% 50V
C1119 1-112-114-11 ELECT 22uF 20% 50V
C1120 1-112-114-11 ELECT 22uF 20% 50V
C1121 1-112-114-11 ELECT 22uF 20% 50V
C1122 1-112-114-11 ELECT 22uF 20% 50V
C1123 1-112-114-11 ELECT 22uF 20% 50V
C1124 1-112-114-11 ELECT 22uF 20% 50V
C1201 1-112-114-11 ELECT 22uF 20% 50V
C1211 1-112-114-11 ELECT 22uF 20% 50V
C1221 1-112-114-11 ELECT 22uF 20% 50V
C1231 1-112-114-11 ELECT 22uF 20% 50V
C1241 1-112-114-11 ELECT 22uF 20% 50V
C1242 1-112-114-11 ELECT 22uF 20% 50V
