Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
158
STR-DA3200ES/DG1000
R4011 1-249-429-11 CARBON 10K 5% 1/4W
0 R4012 1-249-393-11 CARBON 10 5% 1/4W F
0 R4013 1-249-393-11 CARBON 10 5% 1/4W F
0 R4014 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY1101 1-755-486-11 RELAY
RY1102 1-755-486-11 RELAY
RY1103 1-755-486-11 RELAY
RY1104 1-755-486-11 RELAY
RY1401 1-755-486-11 RELAY
RY1402 1-755-031-11 RELAY
RY4001 1-515-920-11 RELAY (24V)
RY4002 1-515-920-11 RELAY (24V)
RY4003 1-515-920-11 RELAY (24V)
< TERMINAL >
TM4001 1-780-405-11 TERMINAL BOARD (SP) (2P)
(SPEAKERS CENTER)
TM4002 1-780-404-11 TERMINAL BOARD (SP) (8P)
(SPEAKERS FRONT A/B)
************************************************************
MIC BOARD
**********
< CAPACITOR >
C755 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN718 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< JACK >
J701 1-820-056-11 SMALL TYPE JACK (AUTO CAL MIC)
< LEAD >
W701 1-775-377-21 LEAD (WITH CONNECTOR)
************************************************************
POWER AMP BOARD
*****************
< CAPACITOR >
C1512 1-107-597-11 CERAMIC 22PF 5% 500V
C1513 1-107-597-11 CERAMIC 22PF 5% 500V
C1562 1-107-597-11 CERAMIC 22PF 5% 500V
C1563 1-107-597-11 CERAMIC 22PF 5% 500V
C1612 1-107-597-11 CERAMIC 22PF 5% 500V
C1613 1-107-597-11 CERAMIC 22PF 5% 500V
C1712 1-107-597-11 CERAMIC 22PF 5% 500V
C1713 1-107-597-11 CERAMIC 22PF 5% 500V
C1762 1-107-597-11 CERAMIC 22PF 5% 500V
C1763 1-107-597-11 CERAMIC 22PF 5% 500V
C1812 1-107-597-11 CERAMIC 22PF 5% 500V
C1813 1-107-597-11 CERAMIC 22PF 5% 500V
C1862 1-107-597-11 CERAMIC 22PF 5% 500V
C1863 1-107-597-11 CERAMIC 22PF 5% 500V
C1903 1-112-857-21 ELECT 100uF 20% 100V
C1904 1-112-857-21 ELECT 100uF 20% 100V
< CONNECTOR >
CN1901 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CNP1903 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
CNP1904 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
< COIL >
L1501 1-420-872-52 COIL, AIR-CORE
L1551 1-420-872-52 COIL, AIR-CORE
L1601 1-420-872-52 COIL, AIR-CORE
L1701 1-420-872-52 COIL, AIR-CORE
L1751 1-420-872-52 COIL, AIR-CORE
L1801 1-420-872-52 COIL, AIR-CORE
L1851 1-420-872-52 COIL, AIR-CORE
< RESISTOR >
0 R1515 1-249-405-11 CARBON 100 5% 1/4W F
0 R1516 1-234-572-21 ENCAPSULATED COMPONENT F
0 R1517 1-249-405-11 CARBON 100 5% 1/4W F
0 R1518 1-249-393-11 CARBON 10 5% 1/4W F
0 R1565 1-249-405-11 CARBON 100 5% 1/4W F
0 R1566 1-234-572-21 ENCAPSULATED COMPONENT F
0 R1567 1-249-405-11 CARBON 100 5% 1/4W F
0 R1568 1-249-393-11 CARBON 10 5% 1/4W F
0 R1615 1-249-405-11 CARBON 100 5% 1/4W F
0 R1616 1-234-572-21 ENCAPSULATED COMPONENT F
0 R1617 1-249-405-11 CARBON 100 5% 1/4W F
0 R1618 1-249-393-11 CARBON 10 5% 1/4W F
0 R1715 1-249-405-11 CARBON 100 5% 1/4W F
0 R1716 1-234-572-21 ENCAPSULATED COMPONENT F
0 R1717 1-249-405-11 CARBON 100 5% 1/4W F
0 R1718 1-249-393-11 CARBON 10 5% 1/4W F
0 R1765 1-249-405-11 CARBON 100 5% 1/4W F
0 R1766 1-234-572-21 ENCAPSULATED COMPONENT F
0 R1767 1-249-405-11 CARBON 100 5% 1/4W F
0 R1768 1-249-393-11 CARBON 10 5% 1/4W F
0 R1815 1-249-405-11 CARBON 100 5% 1/4W F
0 R1816 1-234-572-21 ENCAPSULATED COMPONENT F
0 R1817 1-249-405-11 CARBON 100 5% 1/4W F
0 R1818 1-249-393-11 CARBON 10 5% 1/4W F
0 R1865 1-249-405-11 CARBON 100 5% 1/4W F
0 R1866 1-234-572-21 ENCAPSULATED COMPONENT F
0 R1867 1-249-405-11 CARBON 100 5% 1/4W F
0 R1868 1-249-393-11 CARBON 10 5% 1/4W F
************************************************************
POWER SW BOARD
****************
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN2 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
< SWITCH >
0 SW1 1-786-377-11 SWITCH, POWER (POWER)
************************************************************
MAIN MIC POWER AMP
POWER SW
