Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
162
STR-DA3200ES/DG1000
IC6701 8-759-663-94 IC LA7106M-TLM
IC6702 8-759-663-94 IC LA7106M-TLM
IC6703 8-759-671-94 IC MC74HC4053AFEL
IC6801 8-759-238-47 IC TC74HCT7007AF (EL)
IC6802 8-759-268-29 IC SN74HC595ANS
IC6803 8-759-268-29 IC SN74HC595ANS
< JACK >
J6101 1-815-360-11 JACK, PIN 3P
(COMPONENT VIDEO MONITOR OUT)
J6102 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO
ASSIGNABLE TV/SAT/DVD/VIDEO 1 IN)
J6401 1-794-978-11 JACK, PIN 3P (VIDEO MONITOR OUT, TV/SAT/
DVD VIDEO IN)
J6402 1-794-978-11 JACK, PIN 3P (VIDEO 1/VIDEO 2 VIDEO OUT,
VIDEO 2 VIDEO IN)
J6403 1-815-043-11 JACK, PIN 2P (VIDEO 1 VIDEO IN,
ZONE 2 VIDEO OUT)
< JUMPER RESISTOR >
JW6801 1-216-864-11 SHORT CHIP 0
JW6802 1-216-864-11 SHORT CHIP 0
JW6803 1-216-864-11 SHORT CHIP 0
JW6804 1-216-864-11 SHORT CHIP 0
JW6805 1-216-864-11 SHORT CHIP 0
JW6807 1-216-864-11 SHORT CHIP 0
JW6808 1-216-864-11 SHORT CHIP 0
JW6809 1-216-864-11 SHORT CHIP 0
JW6810 1-216-864-11 SHORT CHIP 0
JW6811 1-216-864-11 SHORT CHIP 0
JW6812 1-216-864-11 SHORT CHIP 0
JW6813 1-216-864-11 SHORT CHIP 0
JW6814 1-216-864-11 SHORT CHIP 0
JW6815 1-216-864-11 SHORT CHIP 0
JW6816 1-216-864-11 SHORT CHIP 0
JW6817 1-216-864-11 SHORT CHIP 0
JW6818 1-216-864-11 SHORT CHIP 0
< COIL >
L6301 1-469-525-11 INDUCTOR 10uH
L6302 1-469-525-11 INDUCTOR 10uH
L6303 1-469-525-11 INDUCTOR 10uH
L6401 1-408-789-21 INDUCTOR 100uH
L6402 1-408-789-21 INDUCTOR 100uH
L6403 1-408-789-21 INDUCTOR 100uH
L6404 1-408-789-21 INDUCTOR 100uH
L6501 1-408-781-00 INDUCTOR 22uH
L6701 1-469-525-11 INDUCTOR 10uH
L6702 1-469-525-11 INDUCTOR 10uH
L6703 1-469-525-11 INDUCTOR 10uH
L6704 1-469-525-11 INDUCTOR 10uH
L6801 1-424-700-21 INDUCTOR 100uH
< TRANSISTOR >
Q6101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6301 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q6302 8-729-216-31 TRANSISTOR 2SA1163-G
Q6303 8-729-216-31 TRANSISTOR 2SA1163-G
Q6304 8-729-216-31 TRANSISTOR 2SA1163-G
Q6305 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q6306 8-729-216-31 TRANSISTOR 2SA1163-G
Q6307 8-729-216-31 TRANSISTOR 2SA1163-G
Q6501 8-729-140-97 TRANSISTOR 2SB734-34
Q6502 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q6503 8-729-216-31 TRANSISTOR 2SA1163-G
Q6504 8-729-216-31 TRANSISTOR 2SA1163-G
< RESISTOR >
R6101 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6102 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6103 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6104 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6105 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6106 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6107 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6108 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6109 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6110 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6111 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6112 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6113 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6120 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R6121 1-249-393-11 CARBON 10 5% 1/4W F
R6131 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R6132 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R6133 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R6134 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R6135 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R6136 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R6137 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R6138 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R6139 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R6140 1-216-804-11 METAL CHIP 39 5% 1/10W
R6141 1-216-804-11 METAL CHIP 39 5% 1/10W
R6142 1-216-804-11 METAL CHIP 39 5% 1/10W
R6307 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6308 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6309 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6310 1-216-847-11 METAL CHIP 150K 5% 1/10W
R6311 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6312 1-216-809-11 METAL CHIP 100 5% 1/10W
R6313 1-218-834-11 METAL CHIP 300 0.5% 1/10W
R6314 1-216-864-11 SHORT CHIP 0
R6315 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6316 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6317 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6318 1-216-809-11 METAL CHIP 100 5% 1/10W
R6319 1-216-809-11 METAL CHIP 100 5% 1/10W
R6320 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6321 1-216-864-11 SHORT CHIP 0
R6322 1-216-864-11 SHORT CHIP 0
R6323 1-216-864-11 SHORT CHIP 0
R6324 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6325 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6326 1-216-797-11 METAL CHIP 10 5% 1/10W
R6327 1-216-797-11 METAL CHIP 10 5% 1/10W
VIDEO
