Sony STR-DA3200ES - Page 165

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
165
STR-DA3200ES/DG1000
FB3802 1-216-295-00 SHORT CHIP 0
FB3803 1-216-295-00 SHORT CHIP 0
< IC >
IC3801 6-705-468-01 IC BA33BC0FP-E2
IC3802 6-709-251-01 IC F2602E-01-TR
IC3803 8-759-524-50 IC TC74VHC541FT (EL)
IC3804 8-759-710-97 IC NJM4565M-D
IC3805 6-707-111-01 IC PCM1753DBQR
IC3806 6-705-469-01 IC BA50BC0FP-E2
IC3807 6-706-740-01 IC BA00BC0WFP-E2
< JACK >
J3801 1-793-642-21 CONNECTOR (USB) (4P), SQUARE (XM)
< JUMPER RESISTOR >
L3801 1-216-295-00 SHORT CHIP 0
L3802 1-216-295-00 SHORT CHIP 0
< TRANSISTOR >
Q3801 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q3802 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q3805 6-550-044-01 TRANSISTOR 2SB1689-T106
Q3806 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R3786 1-216-814-11 METAL CHIP 270 5% 1/10W
R3794 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3798 1-216-864-11 SHORT CHIP 0
R3801 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3802 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3803 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3804 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3805 1-216-809-11 METAL CHIP 100 5% 1/10W
R3806 1-216-809-11 METAL CHIP 100 5% 1/10W
R3807 1-216-809-11 METAL CHIP 100 5% 1/10W
R3808 1-216-809-11 METAL CHIP 100 5% 1/10W
R3809 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3811 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3812 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3815 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3816 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3817 1-216-809-11 METAL CHIP 100 5% 1/10W
R3818 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3819 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3820 1-216-834-11 METAL CHIP 12K 5% 1/10W
R3821 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3822 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3823 1-216-819-11 METAL CHIP 680 5% 1/10W
R3824 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R3825 1-216-809-11 METAL CHIP 100 5% 1/10W
R3826 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3827 1-216-809-11 METAL CHIP 100 5% 1/10W
R3828 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3829 1-216-809-11 METAL CHIP 100 5% 1/10W
R3830 1-216-809-11 METAL CHIP 100 5% 1/10W
R3831 1-216-809-11 METAL CHIP 100 5% 1/10W
R3832 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R3833 1-216-819-11 METAL CHIP 680 5% 1/10W
R3834 1-216-809-11 METAL CHIP 100 5% 1/10W
R3837 1-216-834-11 METAL CHIP 12K 5% 1/10W
R3838 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3839 1-216-809-11 METAL CHIP 100 5% 1/10W
R3840 1-216-809-11 METAL CHIP 100 5% 1/10W
R3841 1-216-809-11 METAL CHIP 100 5% 1/10W
R3842 1-216-809-11 METAL CHIP 100 5% 1/10W
R3843 1-216-809-11 METAL CHIP 100 5% 1/10W
R3844 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3845 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3846 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3847 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3852 1-216-809-11 METAL CHIP 100 5% 1/10W
R3853 1-216-809-11 METAL CHIP 100 5% 1/10W
R3854 1-216-809-11 METAL CHIP 100 5% 1/10W
R3855 1-216-809-11 METAL CHIP 100 5% 1/10W
R3856 1-216-811-11 METAL CHIP 150 5% 1/10W
R3857 1-216-864-11 SHORT CHIP 0
R3858 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R3859 1-216-864-11 SHORT CHIP 0
R3860 1-216-864-11 SHORT CHIP 0
R3861 1-216-864-11 SHORT CHIP 0
R3862 1-216-864-11 SHORT CHIP 0
R3863 1-216-864-11 SHORT CHIP 0
R3864 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3865 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3866 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R3867 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R3869 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X3701 1-760-841-11 VIBRATOR, CRYSTAL (45.1584MHz)
************************************************************
XM
