26
STR-DA3200ES/DG1000
Display
YUV Y DRIVE [XX]
YUV U DRIVE [XX]
YUV V DRIVE [XX]
STOP CLK [XX] [XX] [XX]
Remark
XX: Gain control value of brighness (00 to 1F)
(switching with M m button of the remote commander)
XX: Gain control value of color difference (Cb) (00 to 1F)
(switching with M m button of the remote commander)
XX: Gain control value of color difference (Cr) (00 to 1F)
(switching with M m button of the remote commander)
Value of register related to clock of system controller display mode (for
design evaluation)
Items
YUV Y drive
YUV U drive
YUV V drive
Stop clock
