Digital Component Hookups
Connect the digital output jacks of your DVD player and
satellite tuner (etc ) to the receiver’s digital input jacks to
bring the multi channel surround sound of a movie
theater into your home To enjoy full effect of multi
channel surround sound, five speakers (two front
speakers, two rear speakers, and a center speaker) and a
sub woofer are required You can also connect an LD
player with an RF OUT jack via an RF demodulator, like
r
.
Optical digital cords (not supplied)
0”
Black
m
Black %
Coaxial digital cord (not supplied)
3
Yellow a=- Yellow
s
Audio/video cords (not supplied)
s
the Sony MOD-RF1 (not supplied)
TV or satellite tuner
p!g
when connecting a cord, be sure to match the color-coded pins to
the appropriate jacks on the components
White (L/audio) White (L/audio)
* Make either coaxial or optical connections We recommend making coaxial connections instead of optical connections
Please note that you cannot connect an LD player’s AC-3 RF OUT jack directly to this unit’s digital input jacks You must
first convert the RF signal to either an optical or coaxial digital signal Connect the LD player to the RF demodulator, then
connect the RF demodulator’s optical or coaxial digital output to this unit’s OPTICAL or COAXIAL DVD/LD IN jack
Refer to the instruction manual supplied with your RF Demodulator for details on AC-3 RF hookups
DVDILD
VIDEO IN 1
Note
When making connections as shown above, be sure to set INPUT MODE (m on page
INPUT MODE is set to “AUTO ”
27) manually This unit may not operate correctly if
