Sony STR-DB870 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
69
STR-DB870/DB1070
R1412 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R1413 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1414 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1415 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1416 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1417 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1418 1-216-025-11 RES-CHIP 100 5% 1/10W
R1419 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1420 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1421 1-216-025-11 RES-CHIP 100 5% 1/10W
R1422 1-216-025-11 RES-CHIP 100 5% 1/10W
R1423 1-216-025-11 RES-CHIP 100 5% 1/10W
R1424 1-216-025-11 RES-CHIP 100 5% 1/10W
R1425 1-216-025-11 RES-CHIP 100 5% 1/10W
R1426 1-216-025-11 RES-CHIP 100 5% 1/10W
R1427 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1428 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1429 1-216-295-11 SHORT 0
R1430 1-216-025-11 RES-CHIP 100 5% 1/10W
R1431 1-216-121-11 RES-CHIP 1M 5% 1/10W
R1432 1-216-025-11 RES-CHIP 100 5% 1/10W
R1433 1-216-029-00 METAL CHIP 150 5% 1/10W
R1434 1-216-025-11 RES-CHIP 100 5% 1/10W
R1435 1-216-025-11 RES-CHIP 100 5% 1/10W
R1436 1-216-025-11 RES-CHIP 100 5% 1/10W
R1437 1-216-033-00 METAL CHIP 220 5% 1/10W
R1501 1-216-025-11 RES-CHIP 100 5% 1/10W
R1502 1-216-025-11 RES-CHIP 100 5% 1/10W
R1503 1-216-025-11 RES-CHIP 100 5% 1/10W
R1504 1-216-025-11 RES-CHIP 100 5% 1/10W
R1505 1-216-025-11 RES-CHIP 100 5% 1/10W
R1506 1-216-025-11 RES-CHIP 100 5% 1/10W
R1507 1-216-025-11 RES-CHIP 100 5% 1/10W
R1508 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1509 1-216-295-11 SHORT 0
R1510 1-216-025-11 RES-CHIP 100 5% 1/10W
R1512 1-216-025-11 RES-CHIP 100 5% 1/10W
R1513 1-216-025-11 RES-CHIP 100 5% 1/10W
R1566 1-216-025-11 RES-CHIP 100 5% 1/10W
R1601 1-216-025-11 RES-CHIP 100 5% 1/10W
R1602 1-216-025-11 RES-CHIP 100 5% 1/10W
R1603 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1605 1-216-025-11 RES-CHIP 100 5% 1/10W
R1606 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1607 1-216-025-11 RES-CHIP 100 5% 1/10W
R1608 1-216-295-11 SHORT 0
R1609 1-216-025-11 RES-CHIP 100 5% 1/10W
R1610 1-216-025-11 RES-CHIP 100 5% 1/10W
R1611 1-216-025-11 RES-CHIP 100 5% 1/10W
R1612 1-216-033-00 METAL CHIP 220 5% 1/10W
R1650 1-216-025-11 RES-CHIP 100 5% 1/10W
R1651 1-216-025-11 RES-CHIP 100 5% 1/10W
R1653 1-216-025-11 RES-CHIP 100 5% 1/10W
R1654 1-216-025-11 RES-CHIP 100 5% 1/10W
R1655 1-216-025-11 RES-CHIP 100 5% 1/10W
R1656 1-216-025-11 RES-CHIP 100 5% 1/10W
R1657 1-216-025-11 RES-CHIP 100 5% 1/10W
R1666 1-216-025-11 RES-CHIP 100 5% 1/10W
R1667 1-216-295-11 SHORT 0
R1701 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1702 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1703 1-216-001-00 METAL CHIP 10 5% 1/10W
R1704 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1705 1-216-025-11 RES-CHIP 100 5% 1/10W
R1706 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1707 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1708 1-216-025-11 RES-CHIP 100 5% 1/10W
R1709 1-216-025-11 RES-CHIP 100 5% 1/10W
R1710 1-216-025-11 RES-CHIP 100 5% 1/10W
R1711 1-216-025-11 RES-CHIP 100 5% 1/10W
R1712 1-216-025-11 RES-CHIP 100 5% 1/10W
R1713 1-216-025-11 RES-CHIP 100 5% 1/10W
R1714 1-216-025-11 RES-CHIP 100 5% 1/10W
R1715 1-216-025-11 RES-CHIP 100 5% 1/10W
R1716 1-216-025-11 RES-CHIP 100 5% 1/10W
R1717 1-216-025-11 RES-CHIP 100 5% 1/10W
R1718 1-216-025-11 RES-CHIP 100 5% 1/10W
R1719 1-216-025-11 RES-CHIP 100 5% 1/10W
R1720 1-216-025-11 RES-CHIP 100 5% 1/10W
R1721 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R1722 1-216-025-11 RES-CHIP 100 5% 1/10W
R1723 1-216-025-11 RES-CHIP 100 5% 1/10W
R1724 1-216-025-11 RES-CHIP 100 5% 1/10W
R1725 1-216-025-11 RES-CHIP 100 5% 1/10W
R1726 1-216-025-11 RES-CHIP 100 5% 1/10W
R1727 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R1728 1-216-025-11 RES-CHIP 100 5% 1/10W
R1729 1-216-025-11 RES-CHIP 100 5% 1/10W
R1730 1-216-025-11 RES-CHIP 100 5% 1/10W
R1731 1-216-025-11 RES-CHIP 100 5% 1/10W
R1732 1-216-025-11 RES-CHIP 100 5% 1/10W
R1733 1-216-025-11 RES-CHIP 100 5% 1/10W
R1734 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1735 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1736 1-216-097-11 RES-CHIP 100K 5% 1/10W
R1737 1-216-097-11 RES-CHIP 100K 5% 1/10W
R1738 1-216-097-11 RES-CHIP 100K 5% 1/10W
R1739 1-216-025-11 RES-CHIP 100 5% 1/10W
R1740 1-216-025-11 RES-CHIP 100 5% 1/10W
R1741 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1742 1-216-033-00 METAL CHIP 220 5% 1/10W
R1743 1-216-025-11 RES-CHIP 100 5% 1/10W
R1744 1-216-025-11 RES-CHIP 100 5% 1/10W
R1745 1-216-025-11 RES-CHIP 100 5% 1/10W
(CND, US)
R1746 1-216-025-11 RES-CHIP 100 5% 1/10W
(CND, US)
R1747 1-216-025-11 RES-CHIP 100 5% 1/10W
R1748 1-216-025-11 RES-CHIP 100 5% 1/10W
(CND, US)
R1749 1-216-025-11 RES-CHIP 100 5% 1/10W
R1750 1-216-025-11 RES-CHIP 100 5% 1/10W
R1751 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1752 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1753 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1754 1-216-073-00 RES-CHIP 10K 5% 1/10W
DIGITAL
