Sony STR-DB870 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
70
STR-DB870/DB1070
R1755 1-216-025-11 RES-CHIP 100 5% 1/10W
R1756 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1757 1-216-295-11 SHORT 0 (DB1070)
R1758 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1759 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(E2, E3)
R1759 1-216-073-00 RES-CHIP 10K 5% 1/10W
(CH, KR, MY, SP, TW)
R1759 1-216-295-11 SHORT 0 (AEP, UK)
R1760 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1761 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1762 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1763 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1764 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1765 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1766 1-216-025-11 RES-CHIP 100 5% 1/10W
R1767 1-216-049-11 RES-CHIP 1K 5% 1/10W
(AEP, UK)
R1768 1-216-025-11 RES-CHIP 100 5% 1/10W
R1769 1-216-077-00 RES-CHIP 15K 5% 1/10W
(DB1070)
R1770 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1771 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1772 1-216-033-00 METAL CHIP 220 5% 1/10W
R1773 1-216-025-11 RES-CHIP 100 5% 1/10W
R1774 1-216-033-00 METAL CHIP 220 5% 1/10W
R1775 1-216-025-11 RES-CHIP 100 5% 1/10W
R1776 1-216-025-11 RES-CHIP 100 5% 1/10W
R1777 1-216-025-11 RES-CHIP 100 5% 1/10W
R1778 1-216-033-00 METAL CHIP 220 5% 1/10W
R1779 1-216-025-11 RES-CHIP 100 5% 1/10W
R1780 1-216-025-11 RES-CHIP 100 5% 1/10W
R1781 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1782 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1783 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1784 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1785 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1786 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1787 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1788 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1789 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1790 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1791 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1792 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1793 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1794 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1795 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1796 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1797 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1798 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1799 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1800 1-216-033-00 METAL CHIP 220 5% 1/10W
R1801 1-216-045-00 METAL CHIP 680 5% 1/10W
R1802 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1803 1-216-045-00 METAL CHIP 680 5% 1/10W
R1804 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1805 1-216-045-00 METAL CHIP 680 5% 1/10W
R1806 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1807 1-216-045-00 METAL CHIP 680 5% 1/10W
R1808 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1809 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1810 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1811 1-216-033-00 METAL CHIP 220 5% 1/10W
(AEP, CH, E, UK)
R1812 1-216-033-00 METAL CHIP 220 5% 1/10W
R1813 1-216-033-00 METAL CHIP 220 5% 1/10W
R1814 1-216-033-00 METAL CHIP 220 5% 1/10W
R1815 1-216-025-11 RES-CHIP 100 5% 1/10W
< VIBRATOR >
X1301 1-781-536-11 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
X1401 1-795-219-21 VIBRATOR, CRYSTAL (24.576MHz)
X1501 1-795-297-21 VIBRATOR, CERAMIC (13.5MHz)
X1601 1-795-264-21 VIBRATOR, CERAMIC (13.5MHz)
X1701 1-795-179-21 VIBRATOR, CERAMIC (16.5MHz)
**************************************************************
A-4476-467-A DISP BOARD, COMPLETE (DB870)
A-4476-500-A DISP BOARD, COMPLETE (DB1070)
*********************
* 4-921-941-01 CUSHION (FL)
* 4-990-797-01 HOLDER (FL)
< CAPACITOR >
C1601 1-126-967-11 ELECT 47uF 20% 50V
C1602 1-164-159-11 CERAMIC 0.1uF 50V
C1603 1-164-159-11 CERAMIC 0.1uF 50V
C1607 1-164-159-11 CERAMIC 0.1uF 50V
C1608 1-164-159-11 CERAMIC 0.1uF 50V
C1609 1-164-159-11 CERAMIC 0.1uF 50V
C1610 1-164-159-11 CERAMIC 0.1uF 50V
C1611 1-164-159-11 CERAMIC 0.1uF 50V
C1612 1-164-159-11 CERAMIC 0.1uF 50V
C1613 1-164-159-11 CERAMIC 0.1uF 50V
C1614 1-164-159-11 CERAMIC 0.1uF 50V
C1615 1-164-159-11 CERAMIC 0.1uF 50V
C1616 1-164-159-11 CERAMIC 0.1uF 50V
C1617 1-162-282-31 CERAMIC 100PF 10% 50V
C1618 1-162-282-31 CERAMIC 100PF 10% 50V
C1619 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CN1601 1-784-792-11 CONNECTOR, FFC 31P
CN1602 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
* CN1603 1-568-056-11 PIN, BOARD TO BOARD 8P
CN1604 1-784-807-11 CONNECTOR, BOARD TO BOARD 13P
< LED >
D1601 8-719-075-60 LED SELS5823C-TP15 (VIDEO 1)
D1602 8-719-075-60 LED SELS5823C-TP15 (VIDEO 2)
D1603 8-719-075-60 LED SELS5823C-TP15 (VIDEO 3)
D1604 8-719-075-60 LED SELS5823C-TP15 (DVD/LD)
D1605 8-719-075-60 LED SELS5823C-TP15 (TV/SAT)
D1606 8-719-075-60 LED SELS5823C-TP15
(MD/TAPE (DB870), TAPE (DB1070))
D1607 8-719-075-60 LED SELS5823C-TP15 (CD/SACD) (DB1070)
DIGITAL DISP
