Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
71
STR-DB870/DB1070
D1608 8-719-075-60 LED SELS5823C-TP15
(CD/SACD (DB870), MD/DAT (DB1070)
D1609 8-719-075-60 LED SELS5823C-TP15 (TUNER)
D1610 8-719-075-60 LED SELS5823C-TP15 (PHONO)
D1611 8-719-313-50 LED SEL6810A-TH12 (DIMMER)
D1612 8-719-075-59 LED SELS5B23C-TP15
(DIGITAL CINEMA SOUND)
D1613 8-719-075-59 LED SELS5B23C-TP15 (6.1CH DECODING)
D1614 8-719-046-39 LED SEL5821A-TP15 (NIGHT MODE)
D1615 8-719-046-39 LED SEL5821A-TP15 (MULTI/2CH A.DIRECT)
D1616 8-719-046-39 LED SEL5821A-TP15 (2CH)
D1617 8-719-046-39 LED SEL5821A-TP15 (MODE)
D1618 8-719-046-39 LED SEL5821A-TP15 (A.F.D.)
D1619 8-719-084-07 LED SEL5E20CTP15
(MULTI CHANNEL DECODING)
< FLUORESCENT INDICATOR TUBE >
FL1601 1-518-737-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC1601 8-759-679-75 IC ML9261MB
IC1602 8-759-373-50 IC NJU3719L
IC1603 8-759-036-90 IC MC74ACT08N
IC1610 8-759-036-90 IC MC74ACT08N
< TRANSISTOR >
Q1602 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
0 R1601 1-249-381-11 CARBON 1 5% 1/4W F
0 R1602 1-249-381-11 CARBON 1 5% 1/4W F
R1607 1-249-429-11 CARBON 10K 5% 1/4W
R1608 1-249-429-11 CARBON 10K 5% 1/4W
R1609 1-249-429-11 CARBON 10K 5% 1/4W
R1610 1-249-429-11 CARBON 10K 5% 1/4W
R1617 1-249-429-11 CARBON 10K 5% 1/4W
R1618 1-249-429-11 CARBON 10K 5% 1/4W
R1629 1-249-437-11 CARBON 47K 5% 1/4W
R1630 1-249-437-11 CARBON 47K 5% 1/4W
R1631 1-249-409-11 CARBON 220 5% 1/4W
R1632 1-249-411-11 CARBON 330 5% 1/4W
R1633 1-249-411-11 CARBON 330 5% 1/4W
R1634 1-249-411-11 CARBON 330 5% 1/4W
R1635 1-249-411-11 CARBON 330 5% 1/4W
R1636 1-249-411-11 CARBON 330 5% 1/4W
R1637 1-249-402-11 CARBON 56 5% 1/4W
R1638 1-249-409-11 CARBON 220 5% 1/4W
R1640 1-249-429-11 CARBON 10K 5% 1/4W
R1641 1-247-807-31 CARBON 100 5% 1/4W
R1642 1-247-807-31 CARBON 100 5% 1/4W
R1643 1-247-807-31 CARBON 100 5% 1/4W
R1644 1-247-807-31 CARBON 100 5% 1/4W
R1645 1-247-807-31 CARBON 100 5% 1/4W
R1646 1-247-807-31 CARBON 100 5% 1/4W
R1647 1-247-807-31 CARBON 100 5% 1/4W
R1648 1-247-807-31 CARBON 100 5% 1/4W
< ROTARY ENCODER >
RV1601 1-418-773-11 ENCODER, ROTARY (MASTER VOLUME)
**************************************************************
1-681-103-11 H.P BOARD
**********
< CONNECTOR >
CN749 1-784-922-11 PIN, CONNECTOR 5P
< TERMINAL >
* EB749 1-537-738-21 TERMINAL, EARTH
< JACK >
J749 1-815-313-21 JACK (PHONES)
**************************************************************
A-4476-485-A MAIN BOARD, COMPLETE (DB870: CND)
A-4476-486-A MAIN BOARD, COMPLETE (DB870: AEP, UK)
A-4476-498-A MAIN BOARD, COMPLETE (US)
A-4476-510-A MAIN BOARD, COMPLETE (DB1070: CND)
A-4476-511-A MAIN BOARD, COMPLETE
(CH, E2, E3, KR, MY, SP, TW)
A-4476-527-A MAIN BOARD, COMPLETE (DB1070: AEP, UK)
*********************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C107 1-128-825-11 CERAMIC 2200PF 5% 50V
C108 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP, CH, E, UK)
C109 1-128-813-11 CERAMIC 220PF 5% 50V
(AEP, CH, E, UK)
C110 1-119-821-11 ELECT MELF 2.2uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C110 1-135-740-11 ELECT 2.2uF 50V
(DB1070: AEP, UK)
C111 1-128-832-11 ELECT 220uF 20% 10V
(DB870/DB1070: CH, CND, E, US)
C111 1-135-667-11 ELECT 220uF 10V
(DB1070: AEP, UK)
C112 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP, CH, E, UK)
C113 1-125-896-11 MYLAR 0.0091uF 5% 50V
C114 1-136-159-00 MYLAR 0.033uF 5% 50V
C115 1-119-821-11 ELECT MELF 2.2uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C115 1-135-740-11 ELECT 2.2uF 50V
(DB1070: AEP, UK)
C123 1-128-858-11 ELECT 22uF 20% 50V
(DB1070: CH, CND, E, US)
C123 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C124 1-128-858-11 ELECT 22uF 20% 50V
(DB1070: CH, CND, E, US)
C124 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C125 1-128-809-11 CERAMIC 100PF 5% 50V
(DB1070)
DISP H.P MAIN
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
