Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
73
STR-DB870/DB1070
C518 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C519 1-128-809-11 CERAMIC 100PF 5% 50V
C520 1-136-163-00 MYLAR 0.068uF 5% 50V
C551 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C551 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C552 1-128-813-11 CERAMIC 220PF 5% 50V
C554 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C554 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C555 1-128-813-11 CERAMIC 220PF 5% 50V
C556 1-102-233-00 CERAMIC 33PF 10% 500V
C557 1-128-809-11 CERAMIC 100PF 5% 50V
C558 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C559 1-128-832-11 ELECT 220uF 20% 10V
(DB870/DB1070: CH, CND, E, US)
C559 1-135-667-11 ELECT 220uF 10V
(DB1070: AEP, UK)
C560 1-128-809-11 CERAMIC 100PF 5% 50V
C561 1-107-597-11 CERAMIC 22PF 10% 500V
C562 1-107-597-11 CERAMIC 22PF 10% 500V
C564 1-136-163-00 MYLAR 0.068uF 5% 50V
C567 1-128-840-11 ELECT 47uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C567 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C568 1-136-163-00 MYLAR 0.068uF 5% 50V
C601 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C601 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C602 1-128-813-11 CERAMIC 220PF 5% 50V
C604 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C604 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C605 1-128-813-11 CERAMIC 220PF 5% 50V
C606 1-102-233-00 CERAMIC 33PF 10% 500V
C607 1-128-809-11 CERAMIC 100PF 5% 50V
C608 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C609 1-128-832-11 ELECT 220uF 20% 10V
(DB870/DB1070: CH, CND, E, US)
C609 1-135-667-11 ELECT 220uF 10V
(DB1070: AEP, UK)
C610 1-128-809-11 CERAMIC 100PF 5% 50V
C611 1-107-597-11 CERAMIC 22PF 10% 500V
C612 1-107-597-11 CERAMIC 22PF 10% 500V
C614 1-136-163-00 MYLAR 0.068uF 5% 50V
C617 1-128-809-11 CERAMIC 100PF 5% 50V
C618 1-128-840-11 ELECT 47uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C618 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C619 1-128-809-11 CERAMIC 100PF 5% 50V
C620 1-136-163-00 MYLAR 0.068uF 5% 50V
C651 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C651 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C652 1-128-813-11 CERAMIC 220PF 5% 50V
C654 1-128-858-11 ELECT 22uF 20% 50V
(DB1070: CH, CND, E, US)
C654 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C655 1-128-813-11 CERAMIC 220PF 5% 50V
(DB1070)
C656 1-102-233-00 CERAMIC 33PF 10% 500V
(DB1070)
C657 1-128-809-11 CERAMIC 100PF 5% 50V
(DB1070)
C658 1-102-230-00 CERAMIC 4PF 0.25PF 500V
(DB1070)
C659 1-128-832-11 ELECT 220uF 20% 10V
(DB1070: CH, CND, E, US)
C659 1-135-667-11 ELECT 220uF 10V
(DB1070: AEP, UK)
C660 1-128-809-11 CERAMIC 100PF 5% 50V
(DB1070)
C661 1-107-597-11 CERAMIC 22PF 10% 500V
(DB1070)
C662 1-107-597-11 CERAMIC 22PF 10% 500V
(DB1070)
C664 1-136-163-00 MYLAR 0.068uF 5% 50V
(DB1070)
C667 1-128-840-11 ELECT 47uF 20% 16V
(DB870/DB1070: CH, CND, E, US)
C667 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C668 1-136-163-00 MYLAR 0.068uF 5% 50V
(DB1070)
C701 1-128-858-11 ELECT 22uF 20% 50V
(DB1070: CH, CND, E, US)
C701 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C702 1-128-813-11 CERAMIC 220PF 5% 50V
(DB1070)
C703 1-128-858-11 ELECT 22uF 20% 50V
(DB870/DB1070: CH, CND, E, US)
C703 1-135-744-11 ELECT 22uF 50V
(DB1070: AEP, UK)
C704 1-128-809-11 CERAMIC 100PF 5% 50V
(DB1070)
C718 1-128-840-11 ELECT 47uF 20% 16V
(DB1070: CH, CND, E, US)
C718 1-135-708-11 ELECT 47uF 16V
(DB1070: AEP, UK)
C801 1-127-726-11 ELECT MELF 470uF 20% 25V
(DB870/DB1070: CH, CND, E, US)
C801 1-135-684-11 ELECT 470uF 25V
(DB1070: AEP, UK)
C802 1-127-726-11 ELECT MELF 470uF 20% 25V
(DB870/DB1070: CH, CND, E, US)
C802 1-135-684-11 ELECT 470uF 25V
(DB1070: AEP, UK)
C803 1-136-173-00 MYLAR 0.47uF 5% 50V
C804 1-136-173-00 MYLAR 0.47uF 5% 50V
C809 1-128-883-11 ELECT 22uF 20% 100V
(DB870/DB1070: CH, CND, E, US)
C809 1-135-727-11 ELECT 22uF 100V
(DB1070: AEP, UK)
MAIN
