Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
74
STR-DB870/DB1070
C810 1-128-883-11 ELECT 22uF 20% 100V
(DB870/DB1070: CH, CND, E, US)
C810 1-135-727-11 ELECT 22uF 100V
(DB1070: AEP, UK)
C811 1-128-560-11 ELECT 22uF 20% 100V
C812 1-127-888-11 CERAMIC 0.1uF 10% 50V
C813 1-127-888-11 CERAMIC 0.1uF 10% 50V
C814 1-126-933-11 ELECT 100uF 20% 16V
C815 1-126-933-11 ELECT 100uF 20% 16V
C816 1-127-880-11 CERAMIC 0.022uF 10% 50V
C817 1-135-775-11 ELECT 47uF 35V
C818 1-128-858-11 ELECT 22uF 20% 25V
(DB870/DB1070: CH, CND, E, US)
C818 1-135-703-11 ELECT 22uF 25V
(DB1070: AEP, UK)
C819 1-128-858-11 ELECT 22uF 20% 25V
(DB870/DB1070: CH, CND, E, US)
C819 1-135-703-11 ELECT 22uF 25V
(DB1070: AEP, UK)
C824 1-127-876-11 CERAMIC 0.01uF 10% 50V
< CONNECTOR >
CN101 1-568-828-11 CONNECTOR, FFC 9P
CN801 1-784-922-11 PIN, CONNECTOR 5P
CN802 1-785-102-11 PIN, CONNECTOR 4P
CN803 1-785-102-21 PIN, CONNECTOR 4P
CN804 1-784-923-11 PIN, CONNECTOR 7P
CN805 1-784-926-11 PIN, CONNECTOR 11P
CN806 1-569-814-11 CONNECTOR, BOARD TO BOARD 21P
CN807 1-569-814-11 CONNECTOR, BOARD TO BOARD 21P
CN808 1-564-505-11 PLUG, CONNECTOR 2P
< DIODE >
D301 8-719-911-19 DIODE 1SS199-25 (DB1070)
D801 8-719-911-19 DIODE 1SS199-25
D802 8-719-911-19 DIODE 1SS199-25
D803 8-719-911-19 DIODE 1SS199-25
D809 8-719-911-19 DIODE 1SS199-25
D810 8-719-911-19 DIODE 1SS199-25
D811 8-719-911-19 DIODE 1SS199-25
D813 8-719-911-19 DIODE 1SS199-25 (DB1070)
D814 8-719-911-19 DIODE 1SS199-25
D815 8-719-985-88 DIODE HZS6B2LTA
D816 8-719-911-19 DIODE 1SS199-25
< IC >
IC101 8-759-835-79 IC TC9274N-016
IC102 8-759-582-64 IC TC9273N-004
IC103 8-759-636-74 IC M5218AP-22 (DB1070)
IC104 8-759-636-74 IC M5218AP-22
IC105 8-759-582-66 IC TC9273N-013 (DB1070)
IC401 8-759-835-76 IC TC94A07P
IC402 8-759-636-74 IC M5218AP-22
IC403 8-759-326-52 IC uPC2581V
IC501 8-759-835-76 IC TC94A07P
IC502 8-759-636-74 IC M5218AP-22
IC503 8-759-326-52 IC uPC2581V
IC601 8-759-835-76 IC TC94A07P
IC602 8-759-636-74 IC M5218AP-22
IC603 8-759-326-52 IC uPC2581V
IC701 8-759-835-76 IC TC94A07P (DB1070)
IC702 8-759-636-74 IC M5218AP-22 (DB1070)
IC801 8-759-231-59 IC TA7815S
IC802 8-759-245-87 IC TA7915S
IC804 8-759-036-90 IC MC74ACT08N
IC805 8-759-036-90 IC MC74ACT08N
< JACK >
J301 1-794-981-11 JACK, PIN 4P (PHONO IN, CD/SACD IN)
(DB870)
J301 1-794-982-11 JACK, PIN 4P (PHONO IN, CD/SACD IN)
(DB1070)
J302 1-794-981-11 JACK, PIN 4P (MD/TAPE OUT, MD/TAPE IN)
(DB870)
J302 1-794-982-11 JACK, PIN 4P (MD/DAT OUT, MD/DAT IN)
(DB1070)
J303 1-794-984-11 JACK, PIN 6P (TAPE IN/OUT, 2ND ROOM OUT)
(DB1070)
J304 1-815-543-11 JACK, PIN 6P (MULTI CH IN 1 FRONT/
SURROUND/CENTER/SURROUND BACK)
(DB1070)
J305 1-793-775-12 JACK, PIN 6P (MULTI CH IN FRONT/
SURROUND/CENTER/SUB WOOFER) (DB870)
J305 1-815-543-11 JACK, PIN 6P (MULTI CH IN 2 FRONT/
SURROUND/CENTER/SUB WOOFER) (DB1070)
J307 1-794-974-11 JACK, PIN 1P (SUB WOOFER) (DB1070)
< COIL >
L401 1-420-872-00 COIL, AIR-CORE
L451 1-420-872-00 COIL, AIR-CORE
L501 1-420-872-00 COIL, AIR-CORE
L551 1-420-872-00 COIL, AIR-CORE
L601 1-420-872-00 COIL, AIR-CORE
L651 1-420-872-00 COIL, AIR-CORE (DB1070)
< TRANSISTOR/IC >
Q301 8-729-119-79 TRANSISTOR 2SC2785-FEK (DB1070)
Q401 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q402 8-729-051-92 TRANSISTOR 2SD2560 (DB1070)
Q402 8-749-010-25 IC MN2488-OPY-M (DB870)
Q403 8-729-051-93 TRANSISTOR 2SB1647 (DB1070)
Q403 8-749-010-26 IC MP1620-OPY-M (DB870)
Q451 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q452 8-729-051-92 TRANSISTOR 2SD2560 (DB1070)
Q452 8-749-010-25 IC MN2488-OPY-M (DB870)
Q453 8-729-051-93 TRANSISTOR 2SB1647 (DB1070)
Q453 8-749-010-26 IC MP1620-OPY-M (DB870)
Q501 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q502 8-729-051-92 TRANSISTOR 2SD2560 (DB1070)
Q502 8-749-010-25 IC MN2488-OPY-M (DB870)
Q503 8-729-051-93 TRANSISTOR 2SB1647 (DB1070)
Q503 8-749-010-26 IC MP1620-OPY-M (DB870)
Q551 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q552 8-729-051-92 TRANSISTOR 2SD2560 (DB1070)
Q552 8-749-010-25 IC MN2488-OPY-M (DB870)
Q553 8-729-051-93 TRANSISTOR 2SB1647 (DB1070)
Q553 8-749-010-26 IC MP1620-OPY-M (DB870)
MAIN
