Sony STR-DB870 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
81
STR-DB870/DB1070
C359 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DB1070: AEP, CH, E, UK)
C360 1-127-888-11 CERAMIC 0.1uF 10% 50V
C361 1-126-916-11 ELECT 1000uF 20% 6.3V
(DB1070: AEP, CH, E, UK)
C362 1-126-964-11 ELECT 10uF 20% 50V
(DB1070)
C363 1-126-964-11 ELECT 10uF 20% 50V
C364 1-127-888-11 CERAMIC 0.1uF 10% 50V
C365 1-127-888-11 CERAMIC 0.1uF 10% 50V
C366 1-126-964-11 ELECT 10uF 20% 50V
(DB1070)
C367 1-127-888-11 CERAMIC 0.1uF 10% 50V
C368 1-126-960-11 ELECT 1uF 20% 50V
(DB1070: AEP, CH, E, UK)
C369 1-128-805-11 CERAMIC 47PF 5% 50V
C370 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DB1070: AEP, CH, E, UK)
C372 1-126-916-11 ELECT 1000uF 20% 6.3V
(DB1070: AEP, CH, E, UK)
C373 1-127-888-11 CERAMIC 0.1uF 10% 50V
C374 1-127-888-11 CERAMIC 0.1uF 10% 50V
C375 1-126-964-11 ELECT 10uF 20% 50V
(DB1070)
C376 1-126-960-11 ELECT 1uF 20% 50V
(DB1070: AEP, CH, E, UK)
C377 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DB1070)
C378 1-127-888-11 CERAMIC 0.1uF 10% 50V
C379 1-127-888-11 CERAMIC 0.1uF 10% 50V
(CND, US)
C380 1-127-888-11 CERAMIC 0.1uF 10% 50V
(CND, US)
C381 1-127-888-11 CERAMIC 0.1uF 10% 50V
(CND, US)
C382 1-127-888-11 CERAMIC 0.1uF 10% 50V
(CND, US)
< CONNECTOR >
CN301 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
(DB1070: AEP, CH, E, UK)
CN301 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P
(DB870: AEP, UK)
CN301 1-784-039-21 CONNECTOR, BOARD TO BOARD 19P
(CND, US)
CN302 1-564-505-11 PLUG, CONNECTOR 2P
CN303 1-568-830-11 CONNECTOR, FFC 11P (DB870: AEP, UK)
CN303 1-568-838-11 CONNECTOR, FFC 21P (CND, US)
CN303 1-784-776-11 CONNECTOR, FFC 15P
(DB1070: AEP, CH, E, UK)
* CN306 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P (DB1070)
< TRIMMER >
CT301 1-141-442-11 CAP, CERAMIC TRIMMER 20PF
(DB1070: AEP, CH, E, UK)
CT302 1-141-442-11 CAP, CERAMIC TRIMMER 20PF (DB1070)
CT303 1-141-442-11 CAP, CERAMIC TRIMMER 20PF (DB1070)
< DIODE >
D301 8-719-911-19 DIODE 1SS199-25 (DB1070)
D303 8-719-911-19 DIODE 1SS199-25
D304 8-719-911-19 DIODE 1SS199-25
< FERRITE BEAD/NOISE FILTER >
FB303 1-412-911-11 FERRITE 0uH (DB1070)
FL301 1-424-543-11 FERRITE 0uH
(DB1070: AEP, CH, E, UK)
FL302 1-424-543-11 FERRITE 0uH (DB1070)
FL303 1-424-543-11 FERRITE 0uH
(DB1070: AEP, CH, E, UK)
FL304 1-416-300-21 FILTER, NOISE (DB1070)
FL305 1-416-300-21 FILTER, NOISE (DB1070)
< IC >
IC301 6-700-051-01 IC OPA2652 (CND, US)
IC302 6-700-051-01 IC OPA2652 (CND, US)
IC303 8-759-231-66 IC TC74HC4053AP (CND, US)
IC304 8-759-917-18 IC SN74HCU04AN (DB1070)
IC305 8-759-666-34 IC BA7622 (DB1070)
IC306 8-759-232-01 IC TC74HC00AP (DB1070: AEP, CH, E, UK)
IC307 6-700-367-01 IC MB90089F-G-238-BND (DB1070)
IC308 8-759-529-20 IC NJM2296D
IC309 8-759-822-05 IC LA7213 (DB1070: AEP, CH, E, UK)
IC310 8-759-036-90 IC MC74ACT08N (DB1070)
IC311 8-759-822-05 IC LA7213 (DB1070: AEP, CH, E, UK)
IC312 8-759-036-90 IC MC74ACT08N
< JACK >
J301 1-794-313-11 JACK, PIN (BLOCK) 9P (COMPONENT VIDEO
MONITOR OUT, TV/SAT IN, DVD/LD IN)
(DB1070: CND, US)
J301 1-815-573-11 JACK, PIN BLOCK 9P (COMPONENT VIDEO
MONITOR OUT, TV/SAT IN, DVD/LD IN)
J302 1-794-970-11 JACK, PIN 1P (MONITOR OUT VIDEO) (DB870)
J302 1-794-971-11 JACK, PIN 1P (MONITOR OUT VIDEO)
(DB1070)
J303 1-563-330-11 JACK (CONTROL A1 II)
J304 1-794-978-11 JACK, PIN 3P (VIDEO 2 IN VIDEO,
VIDEO 1 IN/OUT VIDEO) (DB870)
J304 1-794-979-11 JACK, PIN 3P (VIDEO 2 IN VIDEO,
VIDEO 1 IN/OUT VIDEO) (DB1070)
J305 1-794-978-11 JACK, PIN 3P (TV/SAT IN VIDEO,DVD/LD IN
VIDEO, VIDEO OUT 2 VIDEO) (DB870)
J305 1-794-979-11 JACK, PIN 3P (TV/SAT IN VIDEO, DVD/LD IN
VIDEO, VIDEO OUT 2 VIDEO) (DB1070)
< COIL >
L301 1-410-973-11 INDUCTOR 22uH (DB1070)
< TRANSISTOR >
Q302 8-729-900-80 TRANSISTOR DTC124ES (CND, US)
Q304 8-729-119-79 TRANSISTOR 2SC2785-FEK (DB1070)
Q305 8-729-119-79 TRANSISTOR 2SC2785-FEK (DB1070)
< RESISTOR >
R301 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
R302 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
R303 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
VIDEO
