Sony STR-DB870 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
82
STR-DB870/DB1070
R304 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
R305 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
R306 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
R307 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
R308 1-249-417-11 CARBON 1K 5% 1/4W
(CND, US)
R309 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
R310 1-247-804-11 CARBON 75 5% 1/4W
(CND, US)
R311 1-249-417-11 CARBON 1K 5% 1/4W
(CND, US)
R312 1-249-417-11 CARBON 1K 5% 1/4W
(CND, US)
R313 1-249-411-11 CARBON 330 5% 1/4W
(CND, US)
R314 1-249-433-11 CARBON 22K 5% 1/4W
(CND, US)
R315 1-249-411-11 CARBON 330 5% 1/4W
(CND, US)
R316 1-249-433-11 CARBON 22K 5% 1/4W
(CND, US)
R317 1-247-903-00 CARBON 1M 5% 1/4W
(DB1070: AEP, CH, E, UK)
R318 1-247-804-11 CARBON 75 5% 1/4W
(DB1070: AEP, CH, E, UK)
R319 1-249-411-11 CARBON 330 5% 1/4W
(DB1070: AEP, CH, E, UK)
R320 1-249-417-11 CARBON 1K 5% 1/4W
(DB1070)
R321 1-249-417-11 CARBON 1K 5% 1/4W
(DB1070)
R322 1-249-417-11 CARBON 1K 5% 1/4W
(DB1070)
R323 1-247-804-11 CARBON 75 5% 1/4W
(DB1070: AEP, CH, E, UK)
R324 1-247-903-00 CARBON 1M 5% 1/4W
(DB1070)
R325 1-249-429-11 CARBON 10K 5% 1/4W
(CND, US)
R326 1-249-411-11 CARBON 330 5% 1/4W
(CND, US)
R327 1-249-411-11 CARBON 330 5% 1/4W
(DB1070)
R328 1-247-807-31 CARBON 100 5% 1/4W
(DB1070)
R329 1-249-393-11 CARBON 10 5% 1/4W
(DB1070)
R330 1-249-393-11 CARBON 10 5% 1/4W
(DB1070)
R331 1-249-417-11 CARBON 1K 5% 1/4W
(DB1070)
R332 1-247-807-31 CARBON 100 5% 1/4W
(DB1070: AEP, CH, E, UK)
R333 1-249-425-11 CARBON 4.7K 5% 1/4W
(DB1070)
R334 1-247-807-31 CARBON 100 5% 1/4W
(DB1070: CND, US)
R335 1-247-804-11 CARBON 75 5% 1/4W
(DB1070: AEP, CH, E, UK)
R336 1-247-804-11 CARBON 75 5% 1/4W
(DB1070: AEP, CH, E, UK)
R337 1-249-411-11 CARBON 330 5% 1/4W
(CND, US)
R338 1-247-804-11 CARBON 75 5% 1/4W
R339 1-247-804-11 CARBON 75 5% 1/4W
R340 1-247-804-11 CARBON 75 5% 1/4W
R341 1-247-804-11 CARBON 75 5% 1/4W
R342 1-247-804-11 CARBON 75 5% 1/4W
R343 1-249-437-11 CARBON 47K 5% 1/4W
(DB1070)
R344 1-247-804-11 CARBON 75 5% 1/4W
R345 1-249-437-11 CARBON 47K 5% 1/4W
(DB1070)
R346 1-247-804-11 CARBON 75 5% 1/4W
R347 1-249-424-11 CARBON 3.9K 5% 1/4W
(DB1070)
R348 1-249-437-11 CARBON 47K 5% 1/4W
(DB1070)
R349 1-249-418-11 CARBON 1.2K 5% 1/4W
(DB1070)
R350 1-249-437-11 CARBON 47K 5% 1/4W
(DB1070)
R351 1-247-804-11 CARBON 75 5% 1/4W
R352 1-249-411-11 CARBON 330 5% 1/4W
(DB1070: AEP, CH, E, UK)
R353 1-247-883-00 CARBON 150K 5% 1/4W
(DB1070: AEP, CH, E, UK)
R354 1-249-411-11 CARBON 330 5% 1/4W
(CND, US)
R355 1-249-411-11 CARBON 330 5% 1/4W
(DB1070: AEP, CH, E, UK)
R356 1-247-883-00 CARBON 150K 5% 1/4W
(DB1070: AEP, CH, E, UK)
R357 1-247-807-31 CARBON 100 5% 1/4W
(CND, US)
R358 1-249-433-11 CARBON 22K 5% 1/4W
(CND, US)
R359 1-249-411-11 CARBON 330 5% 1/4W
(CND, US)
< VIBRATOR >
X301 1-781-820-21 VIBRATOR, CRYSTAL (17.34MHz)
(DB1070: AEP, CH, E, UK)
X302 1-781-821-21 VIBRATOR, CRYSTAL (14MHz) (DB1070)
**************************************************************
1-681-104-11 VIDEO 3 BOARD
**************
< CAPACITOR >
C293 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C294 1-162-302-11 CERAMIC 0.0022uF 30% 16V
< CONNECTOR >
CN299 1-784-923-11 PIN, CONNECTOR 7P
* EB299 1-537-738-21 TERMINAL, EARTH
VIDEO VIDEO 3
