Sony STR-DB870 - Page 83

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
83
STR-DB870/DB1070
< JACK >
J298 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P
(VIDEO 3 INPUT VIDEO/AUDIO)
J299 1-784-808-11 TERMINAL, S (VIDEO 3 INPUT S-VIDEO)
< RESISTOR >
R298 1-249-417-11 CARBON 1K 5% 1/4W
R299 1-249-417-11 CARBON 1K 5% 1/4W
**************************************************************
1-681-096-11 VIDEO AU BOARD
***************
< CAPACITOR >
C201 1-127-868-11 CERAMIC 2200PF 10% 50V
C202 1-127-868-11 CERAMIC 2200PF 10% 50V
C211 1-127-868-11 CERAMIC 2200PF 10% 50V
C212 1-127-868-11 CERAMIC 2200PF 10% 50V
C213 1-128-809-11 CERAMIC 100PF 5% 50V
< CONNECTOR >
CN201 1-568-441-11 SOCKET, CONNECTOR 9P
* CN202 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< IC >
IC201 8-759-582-65 IC TC9273N-014
< JACK >
J201 1-774-411-11 JACK, PIN 6P (TV/SAT AUDIO IN, DVD/LD
AUDIO IN, VIDEO 2 AUDIO OUT) (DB870)
J201 1-794-984-11 JACK, PIN 6P (TV/SAT AUDIO IN, DVD/LD
AUDIO IN, VIDEO 2 AUDIO OUT) (DB1070)
J202 1-774-411-11 JACK, PIN 6P (VIDEO 2 AUDIO IN,
VIDEO 1 AUDIO IN/OUT) (DB870)
J202 1-794-984-11 JACK, PIN 6P (VIDEO 2 AUDIO IN,
VIDEO 1 AUDIO IN/OUT) (DB1070)
< RESISTOR >
R201 1-249-417-11 CARBON 1K 5% 1/4W
R202 1-249-417-11 CARBON 1K 5% 1/4W
R203 1-249-421-11 CARBON 2.2K 5% 1/4W
R204 1-249-417-11 CARBON 1K 5% 1/4W
R205 1-249-421-11 CARBON 2.2K 5% 1/4W
R206 1-249-417-11 CARBON 1K 5% 1/4W
R211 1-249-417-11 CARBON 1K 5% 1/4W
R251 1-249-417-11 CARBON 1K 5% 1/4W
R252 1-249-417-11 CARBON 1K 5% 1/4W
R253 1-249-421-11 CARBON 2.2K 5% 1/4W
R254 1-249-417-11 CARBON 1K 5% 1/4W
R255 1-249-421-11 CARBON 2.2K 5% 1/4W
R256 1-249-417-11 CARBON 1K 5% 1/4W
**************************************************************
VIDEO 3 VIDEO AU V.SWITCH
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
1-681-106-11 V.SWITCH BOARD (E2, E3)
**************
1-533-217-31 HOLDER, FUSE
< CONNECTOR >
CN49 1-568-106-11 PIN, CONNECTOR 4P
< FUSE >
0 F49 1-532-504-51 FUSE (T4AL/250V)
< SWITCH >
0 VS49 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)
**************************************************************
MISCELLANEOUS
**************
62 1-765-352-11 WIRE (FLAT TYPE) (31 CORE)
64 1-773-105-11 WIRE (FLAT TYPE) (19 CORE) (CND, US)
160 1-769-904-11 WIRE (FLAT TYPE) (9 CORE)
164 1-693-539-21 TUNER
(DB870: CND/DB1070: CND, E2, E3, US)
164 1-693-540-21 TUNER(DB870: AEP, UK/
DB1070: AEP, CH, KR, MY, SP, TW, UK)
203 1-773-143-11 WIRE (FLAT TYPE) (21 CORE) (CND, US)
204 1-773-001-11 WIRE (FLAT TYPE) (15 CORE) (DB870)
204 1-773-003-11 WIRE (FLAT TYPE) (15 CORE) (DB1070)
0 210 1-769-079-21 CORD, POWER (KR)
0 210 1-769-743-11 CORD, POWER (CND)
0 210 1-777-071-21 CORD, POWER (DB870: AEP, UK/
DB1070:AEP, E2, E3, MY, SP, TW, UK)
0 210 1-782-464-21 CORD, POWER (CH)
0 210 1-783-820-11 CORD, POWER (US)
0 T901 1-437-324-11 TRANSFORMER, POWER (TW)
0 T901 1-437-325-11 TRANSFORMER, POWER (CND, US)
0 T901 1-437-327-11 TRANSFORMER, POWER (DB870: AEP, UK /
DB1070: AEP, CH, KR, MY, SP, UK)
0 T901 1-437-328-11 TRANSFORMER, POWER (E2)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-885-09 SCREW +BVTT 4X16 (S)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-569-008-21 ADAPTOR, CONVERSION (E2, E3, TW)
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
1-476-552-21 COMMANDER, STANDARD (RM-U305A)
(DB870: AEP, UK)
1-476-606-11 REMOTE COMMANDER (RM-PP505)
(DB870: CND)
1-476-607-11 REMOTE COMMANDER (RM-PP505L)
(DB1070: CND, US)
1-476-645-11 REMOTE COMMANDER (RM-LP205)
(DB1070: AEP, CH, E2, E3, KR, MY, SP, TW, UK)
