Sony STR-DE585 - Power SW;Standby Board Parts

49
STR-DE585
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R736 1-249-417-11 CARBON 1K 5% 1/4W
R737 1-249-436-11 CARBON 39K 5% 1/4W
R740 1-249-433-11 CARBON 22K 5% 1/4W
R742 1-249-437-11 CARBON 47K 5% 1/4W
R743 1-249-433-11 CARBON 22K 5% 1/4W
R744 1-249-433-11 CARBON 22K 5% 1/4W
R745 1-249-433-11 CARBON 22K 5% 1/4W
R746 1-249-433-11 CARBON 22K 5% 1/4W
R747 1-249-431-11 CARBON 15K 5% 1/4W
R748 1-247-843-11 CARBON 3.3K 5% 1/4W
R750 1-249-433-11 CARBON 22K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-414-11 CARBON 560 5% 1/4W
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-249-433-11 CARBON 22K 5% 1/4W
R756 1-249-433-11 CARBON 22K 5% 1/4W
R757 1-249-431-11 CARBON 15K 5% 1/4W
R758 1-247-843-11 CARBON 3.3K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W
R764 1-249-405-11 CARBON 100 5% 1/4W
R765 1-249-405-11 CARBON 100 5% 1/4W
R766 1-233-352-41 COMPONENT, ENCAPSULATED 0.22X2 5W
R767 1-249-393-11 CARBON 10 5% 1/4W
R768 1-249-389-11 CARBON 4.7 5% 1/4W
R769 1-249-425-11 CARBON 4.7K 5% 1/4W
R770 1-249-437-11 CARBON 47K 5% 1/4W
R771 1-247-850-11 CARBON 6.2K 5% 1/4W
R772 1-249-419-11 CARBON 1.5K 5% 1/4W
R773 1-249-437-11 CARBON 47K 5% 1/4W
R775 1-249-439-11 CARBON 68K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R780 1-249-429-11 CARBON 10K 5% 1/4W
R791 1-249-425-11 CARBON 4.7K 5% 1/4W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W F
R793 1-249-389-11 CARBON 4.7 5% 1/4W
0 R794 1-215-868-00 METAL OXIDE 680 5% 1W F
R802 1-249-381-11 CARBON 1 5% 1/4W
R803 1-249-389-11 CARBON 4.7 5% 1/4W
R804 1-249-426-11 CARBON 5.6K 5% 1/4W
R806 1-249-433-11 CARBON 22K 5% 1/4W
0 R910 1-243-635-11 FUSIBLE 0.33 5% 1/2W F
RR11 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
RR12 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
RR13 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
RR14 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
RR15 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
< RELAY >
RY501 1-755-421-11 RELAY (12V)
RY560 1-755-267-11 RELAY
RY601 1-755-421-11 RELAY (12V)
RY701 1-755-421-11 RELAY (12V)
RY791 1-755-421-11 RELAY (12V)
< TERMINAL BOARD >
TM601 1-537-510-11 TERMINAL BOARD (6P) (SPEAKERS
SURROUND/CENTER)
TM602 1-537-925-61 TERMINAL BOARD (4P) (SPEAKERS FRONT)
*************************************************************
1-683-759-11 POWER SW BOARD
****************
< CONNECTOR >
CN104 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< RESISTOR >
R138 1-249-433-11 CARBON 22K 5% 1/4W
R139 1-249-437-11 CARBON 47K 5% 1/4W
< SWITCH >
S143 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S144 1-771-410-21 SWITCH, TACTILE (DIMMER)
S145 1-771-410-21 SWITCH, TACTILE (?/1)
*************************************************************
A-4727-841-A STANDBY BOARD, COMPLETE (Canadian)
A-4727-850-A STANDBY BOARD, COMPLETE (AEP,UK)
*************************
1-533-293-11 HOLDER, FUSE
< CAPACITOR >
C813 1-164-159-21 CERAMIC 0.1uF 50V
C814 1-164-159-21 CERAMIC 0.1uF 50V
C815 1-126-943-11 ELECT 2200uF 20% 25V
C816 1-126-941-11 ELECT 470uF 20% 25V
C898 1-126-949-11 ELECT 220uF 20% 35V
C899 1-126-948-11 ELECT 100uF 20% 35V
C920 1-164-159-21 CERAMIC 0.1uF 50V
C921 1-164-159-21 CERAMIC 0.1uF 50V
C923 1-126-959-11 ELECT 0.47uF 20% 50V
C950 1-126-936-11 ELECT 3300uF 20% 16V
< CONNECTOR >
CNP901 1-564-321-00 PIN, CONNECTOR 2P
* CNP902 1-565-792-11 PIN, CONNECTOR 2P
CNP903 1-564-506-11 PLUG, CONNECTOR 3P
CNP905 1-766-203-11 PLUG, CONNECTOR PIN (PC BOARD) 5P
CNP912 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D820 8-719-200-82 DIODE 11ES2
D821 8-719-200-82 DIODE 11ES2
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
MAIN POWER SW STANDBY
