Sony STR-DE585 - Video Board Parts

50
STR-DE585
D822 8-719-200-82 DIODE 11ES2
D823 8-719-200-82 DIODE 11ES2
D898 8-719-200-82 DIODE 11ES2
D899 8-719-200-82 DIODE 11ES2
D901 8-719-991-33 DIODE 1SS133T-77
D910 8-719-200-82 DIODE 11ES2
D911 8-719-200-82 DIODE 11ES2
D912 8-719-200-82 DIODE 11ES2
D913 8-719-200-82 DIODE 11ES2
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* G901 1-537-738-21 TERMINAL, EARTH
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q921 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
0 R810 1-240-877-11 FUSIBLE 0.15 5% 1/2W F
0 R811 1-240-877-11 FUSIBLE 0.15 5% 1/2W F
0 R812 1-240-877-11 FUSIBLE 0.15 5% 1/2W F
0 R901 1-219-237-11 SOLID 3.3M 20% 1/2W F
(Canadian)
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W
R904 1-249-381-11 CARBON 1 5% 1/4W
R921 1-249-437-11 CARBON 47K 5% 1/4W
R922 1-249-435-11 CARBON 33K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-334-11 RELAY, AC POWER (9V)
< TRANSFORMER >
0 T902 1-435-435-11 TRANSFORMER, POWER (AEP,UK)
0 T902 1-435-436-11 TRANSFORMER, POWER (Canadian)
*************************************************************
A-4727-840-A VIDEO BOARD, COMPLETE (Canadian)
A-4727-849-A VIDEO BOARD, COMPLETE (AEP,UK)
**********************
< CAPACITOR >
C200 1-128-805-21 CERAMIC 47PF 5% 50V
C201 1-128-805-21 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-964-11 ELECT 10uF 20% 50V
C214 1-164-159-21 CERAMIC 0.1uF 50V
C215 1-164-159-21 CERAMIC 0.1uF 50V
C248 1-128-825-21 CERAMIC 0.0022uF 5% 50V
C249 1-128-825-21 CERAMIC 0.0022uF 5% 50V
C809 1-126-947-11 ELECT 47uF 20% 25V
C824 1-164-159-21 CERAMIC 0.1uF 50V
C825 1-164-159-21 CERAMIC 0.1uF 50V
C827 1-126-947-11 ELECT 47uF 20% 25V
< CONNECTOR >
CNP156 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS150 1-569-315-11 SOCKET, CONNECTOR 5P
< DIODE >
D203 8-719-991-33 DIODE 1SS133T-77
D204 8-719-991-33 DIODE 1SS133T-77
< IC >
IC103 6-701-890-01 IC NJM2595D
IC804 8-759-701-65 IC NJM79M05FA
IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-770-337-11 JACK, PIN 3P (DVD/LD VIDEO IN,
VIDEO 2 VIDEO IN,VIDEO 1 VIDEO OUT)
J201 1-695-317-11 JACK, PIN 2P (VIDEO 1 VIDEO IN,
MONITOR VIDEO OUT)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STANDBY VIDEO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
