Note
Depending on the TV or video device, 4K or 3D content may not be displayed. Check the HDMI
video formats supported by the receiver.
Refer to the operating instructions of each connected device for details.
[24] Preparation 4. Connecting audio-visual devices and the antennas (aerials)
Connecting devices with HDMI jacks
Connect devices to the receiver as illustrated below.
Before connecting cables, be sure to disconnect the AC power cord (mains lead).
All HDMI jacks on the receiver support HDCP 2.2 (High-bandwidth Digital Content Protection
System Revision 2.2). To watch content protected by HDCP 2.2, such as 4K content, connect
3840 × 2160p @
29.97/30 Hz
○
(*2)
- - -
3840 × 2160p @ 25 Hz
○
(*2)
- - -
3840 × 2160p @
23.98/24 Hz
○
(*2)
- - -
1920 × 1080p @
59.94/60 Hz
○ - ○ ○
1920 × 1080p @ 50 Hz ○ - ○ ○
1920 × 1080p @
29.97/30 Hz
○ ○ ○ ○
1920 × 1080p @ 25 Hz ○ ○ ○ ○
1920 × 1080p @
23.98/24 Hz
○ ○ ○ ○
1920 × 1080i @
59.94/60 Hz
○ ○ ○ ○
1920 × 1080i @ 50 Hz ○ ○ ○ ○
1280 × 720p @
59.94/60 Hz
○ ○ ○ ○
1280 × 720p @ 50 Hz ○ ○ ○ ○
1280 × 720p @
29.97/30 Hz
○ ○ ○ ○
1280 × 720p @
23.98/24 Hz
○ ○ ○ ○
720 × 480p @ 59.94/60
Hz
○ - - -
720 × 576p @ 50 Hz ○ - - -
640 × 480p @ 59.94/60
Hz
○ - - -
If you use YCbCr 4:4:4/YCbCr 4:2:2/RGB 4:4:4 or YCbCr 4:2:0 Deep Color (Deep Colour) (10 bit or 12 bit) of
these video formats, we recommend you to use Premium High Speed HDMI Cables with Ethernet, which can
support bandwidth up to 18 Gbps, and be sure to set the HDMI signal format to [ENHANCED] in the [<HDMI>]
menu. For details, see “Setting HDMI signal format (
SIGNAL FMT.).”
*1
If you use Deep Color (Deep Colour) (10 bit or 12 bit) of these video formats, we recommend you to use
Premium High Speed HDMI Cables with Ethernet, which can support bandwidth up to 18 Gbps, and be sure to
set the HDMI signal format to [ENHANCED] in the [<HDMI>] menu. For details, see “Setting HDMI signal format
(SIGNAL FMT.).”
*2
