Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1050
103
IC4101 6-715-164-01 IC TPS2553DBVR
IC4102 6-717-006-01 IC BD00HC5WEFJ-E2
IC4103 6-719-139-01 IC MM3411A50NRE
IC7000 (Not supplied) IC BD00IC0WHFV-GTR
IC7001 (Not supplied) IC BD00IC0WHFV-GTR
< JACK >
J2100 1-784-431-11 JACK, PIN 1P
(COAXIAL BD/DVD (ASSIGNABLE) IN)
J2701 1-563-330-31 JACK (IR REMOTE IN)
J2702 1-563-330-31 JACK (IR REMOTE OUT)
J7000 1-843-693-11 ETHERNET CONNECTOR (
)
< COIL >
L3001 1-469-525-91 INDUCTOR 10uH
* L3201 1-460-416-11 COMMON MODE CHOKE COIL
* L3202 1-460-416-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
Q2102 6-553-358-01 TR 2PB709BSL
Q2103 6-553-266-01 TR 2PD601ART
Q2104 6-553-266-01 TR 2PD601ART
Q2105 6-553-268-01 TR PDTC114ET
Q2107 6-553-007-01 TR PMG85XP
Q2701 6-553-268-01 TR PDTC114ET
Q3000 6-552-936-01 TR LTC014EUBFS8TL
Q3004 6-552-936-01 TR LTC014EUBFS8TL
Q3005 6-553-007-01 TR PMG85XP
Q3202 6-553-007-01 TR PMG85XP
< RESISTOR >
R2047 1-218-941-81 METAL CHIP 100 5% 1/16W
R2048 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2051 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2052 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2053 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2054 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2055 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2056 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2058 1-216-864-11 SHORT CHIP 0
R2060 1-216-864-11 SHORT CHIP 0
R2061 1-216-864-11 SHORT CHIP 0
R2063 1-216-864-11 SHORT CHIP 0
R2066 1-218-941-81 METAL CHIP 100 5% 1/16W
R2068 1-218-937-11 METAL CHIP 47 5% 1/16W
R2070 1-218-937-11 METAL CHIP 47 5% 1/16W
R2077 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2080 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2081 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2082 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2083 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2084 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2085 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2100 1-218-941-81 METAL CHIP 100 5% 1/16W
R2101 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2103 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2104 1-218-941-81 METAL CHIP 100 5% 1/16W
R2105 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2107 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2108 1-218-941-81 METAL CHIP 100 5% 1/16W
R2110 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R2111 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2112 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2113 1-218-941-81 METAL CHIP 100 5% 1/16W
R2114 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2115 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2117 1-218-941-81 METAL CHIP 100 5% 1/16W
R2118 1-218-941-81 METAL CHIP 100 5% 1/16W
R2119 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2120 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2122 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R2124 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2126 1-218-941-81 METAL CHIP 100 5% 1/16W
R2127 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2128 1-218-941-81 METAL CHIP 100 5% 1/16W
R2129 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2130 1-218-941-81 METAL CHIP 100 5% 1/16W
R2131 1-218-949-11 METAL CHIP 470 5% 1/16W
R2133 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2134 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2135 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2136 1-218-949-11 METAL CHIP 470 5% 1/16W
R2137 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2138 1-218-985-11 METAL CHIP 470K 5% 1/16W
R2140 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2141 1-218-971-81 METAL CHIP 33K 5% 1/16W
R2142 1-218-951-11 METAL CHIP 680 5% 1/16W
R2143 1-218-947-11 METAL CHIP 330 5% 1/16W
R2144 1-218-941-81 METAL CHIP 100 5% 1/16W
R2146 1-218-941-81 METAL CHIP 100 5% 1/16W
R2147 1-218-941-81 METAL CHIP 100 5% 1/16W
R2150 1-218-941-81 METAL CHIP 100 5% 1/16W
R2151 1-218-937-11 METAL CHIP 47 5% 1/16W
R2152 1-218-941-81 METAL CHIP 100 5% 1/16W
R2153 1-218-947-11 METAL CHIP 330 5% 1/16W
R2154 1-218-949-11 METAL CHIP 470 5% 1/16W
R2155 1-218-941-81 METAL CHIP 100 5% 1/16W
R2159 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2161 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2166 1-218-941-81 METAL CHIP 100 5% 1/16W
R2168 1-218-941-81 METAL CHIP 100 5% 1/16W
R2176 1-218-990-81 SHORT CHIP 0
R2177 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2178 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2184 1-218-941-81 METAL CHIP 100 5% 1/16W
R2185 1-218-947-11 METAL CHIP 330 5% 1/16W
R2186 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2187 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R2188 1-218-947-11 METAL CHIP 330 5% 1/16W
R2189 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R2191 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2192 1-218-941-81 METAL CHIP 100 5% 1/16W
R2193 1-218-945-11 METAL CHIP 220 5% 1/16W
R2194 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2195 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2196 1-218-949-11 METAL CHIP 470 5% 1/16W
R2197 1-218-941-81 METAL CHIP 100 5% 1/16W
R2198 1-218-941-81 METAL CHIP 100 5% 1/16W
R2199 1-218-941-81 METAL CHIP 100 5% 1/16W
R2200 1-218-941-81 METAL CHIP 100 5% 1/16W
R2201 1-218-941-81 METAL CHIP 100 5% 1/16W
DIGITAL
Note: IC7000 and IC7001 on the DIGITAL board cannot exchange
with single. When these parts on the DIGITAL board are
damaged, exchange the entire mounted board.
To Next Page
